Default Value: newid() Remarks: Unique ID to identify a record. 2.3.251.3 portnumber (FI-1939) Type: long 2.3.251.4 priority (FI-1848) Type: long 2.3.251.5 sslenabled (FI-1905) Type: bool 2.3.251.6 tkldapprotocol (FI-1846) Type: enum (Not Modifiable) Uniqueness: tkldapprotocol + hostname is unique. (MFI-46) 2.3.252 ldapfilter (TI-283) Description: LDAP Filter Fields: 2.3.252.1 filter (FI-1995) Type: string [8192] Default Value: EMPTY Validation: ^[^\x00-\x1F\x7F""""]{0,2048}$ Remarks: The Filter string to be passed to the LDAP Host in a sync requ possible result records. 2.3.252.2 name (FI-1997) Type: string [256] (Unique) Default Value: EMPTY Validation: ^[^\x00-\x1F\x7F""""]{0,64}$ Remarks: The filter name should help the administrator identify and se reference by a sync agreement. 2.3.252.3 pkid (FI-1993) Type: guid (Unique, Not Modifiable) Default Value: newid() Remarks: Unique ID to identify a record. Uniqueness: No multicolumn uniqueness constraints 2.3.253 ldapsearchagreement (TI-2901) Description: Directory Search LDAP for Edge Clients Fields: 2.3.253.1 distinguishedname (FI-27245) Type: string [255]
