2.3.254.4 tkldapserverattr (FI-27466) Type: enum Remarks: LDAP attribute type mapping. Uniqueness: No multicolumn uniqueness constraints 2.3.255 ldapserverattribute (TI-267) Description: Prepopulated ldap attribute names for each server type Fields: 2.3.255.1 dirobjectname (FI-1898) Type: string [128] (Null OK) 2.3.255.2 pkid (FI-1961) Type: guid (Not Modifiable) Default Value: newid() Remarks: Unique ID to identify a record. 2.3.255.3 tkldapserver (FI-1896) Type: enum 2.3.255.4 tkldapserverattr (FI-1897) Type: enum Uniqueness: No multicolumn uniqueness constraints 2.3.256 ldapsystemconfig (TI-274) Description: LDAP System Config Insert/Delete is not allowed. Fields: 2.3.256.1 pkid (FI-1963) Type: guid (Not Modifiable) Default Value: newid() Remarks: Unique ID to identify a record. 2.3.256.2 syncenabled (FI-1944) Type: bool Default Value: FALSE Remarks: Indicates whether plugin is enabled 2.3.256.3 tkldapserver (FI-1943) Type: enum (Null OK) Default Value: 1 2.3.256.4 useridattributename (FI-1941) Type: string [64] (Null OK)

Image 1 from page 447

Image 2 from page 447

Image 3 from page 447

Image 4 from page 447

Image 5 from page 447

Image 6 from page 447

Image 7 from page 447

Image 8 from page 447

Image 9 from page 447

Image 10 from page 447
