Cisco Unity Connection Notification Interface (CUNI) API
First Published: 2017-02-02
Last Modified: 2022-05-12
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883
Page 2
© 2018 Cisco Systems, Inc. All rights reserved.
Page 3
C O N T E N T S
API Overview
1
C H A P T E R 1
Introduction
1
Technical Details
1
Getting Started with CUNI
2
Other CUNI Resources
2
Troubleshooting
2
Cisco Unity Connection Notification Interface (CUNI) API -- CUNI Event Schema
3
C H A P T E R 2
Schema Example
3
Cisco Unity Connection Notification Interface (CUNI) API -- Subscribing to and Processing Notification
Events
5
C H A P T E R 3
Subscribing to Notification Events
5
Processing Notification Events
6
Cisco Unity Connection Notification Interface (CUNI) API -- CUNI FAQs
9
C H A P T E R 4
CUNI FAQs
9
Cisco Unity Connection Notification Interface (CUNI) API
iii
Page 4
Cisco Unity Connection Notification Interface (CUNI) API
iv
Contents
Page 5
C H A P T E R 1
API Overview
• Introduction, on page 1
• Technical Details , on page 1
• Getting Started with CUNI , on page 2
• Other CUNI Resources , on page 2
• Troubleshooting , on page 2
Introduction
The Cisco Unity Connection Notification Interface (CUNI) API is a web service interface for managing
subscriptions to events from Cisco Unity Connection systems. It provides a way to get asynchronous
notifications when voice mail messages are received, deleted, or changed. CUNI can be used to integrate
Connection into an existing enterprise-wide portal.
CUNI is designed to provide a simple, stable method of accessing the notification functionality on Connection
systems through a standards based interface using XML and HTTPS.
Through CUNI, you can do the following:
• Subscribe for message events
• Subscribe for one or many users on a single channel
Note: All the above functions associated with CUNI API support both the IPv4 and IPv6 addresses. However,
the IPv6 address works only when Connection platform is configured in Dual (IPv4/IPv6) mode.
Note that CUNI is intended for use in server-to-server applications where receiving notifications for many
users over a single connection is required. As such, it is designed to handle a small number of clients that are
each subscribing for notifications on a large set of subscribers. It also requires Administrative credentials,
making it inappropriate for browser applications to use directly.
CUNI is composed of two parts: a SOAP interface for subscribing, and an asynchronous piece (the Notifier)
that delivers events as XML over HTTP.
Technical Details
• CUNI is standards-based: it implements a standard SOAP-based interface for managing subscriptions.
Message events are sent as standard XML over HTTP.
Cisco Unity Connection Notification Interface (CUNI) API
1
Page 6
• CUNI is easy to use: as a web-based interface, CUNI is independent of operating systems and programming
languages, and does not require any client libraries to use.
Getting Started with CUNI
In order to begin developing with CUNI, you need to obtain the following:
Hardware
• Cisco Media Convergence Server (MCS) for Cisco Unity Connection.
• For detailed hardware-specification information, see the Supported Platforms List available at
https://www.cisco.com/c/en/us/support/unified-communications/unity-connection/
products-installation-guides-list.html .
Software
• Cisco Unity Connection Software Ordering
• Not for Resale Kits (Must for eligible to purchase)
• Select Unified Communications System Release Kit
Discounts for some of the above hardware and software may be available for participants in the Cisco
Technology Developer Program.
We recommend that all developers have an up-to-date Cisco Developer Services support agreement. This
provides the developer with access to professional support and assistance for application development.
Other CUNI Resources
Additional information about CUNI is also available on the Cisco Developer Network, see the
https://developer.cisco.com/site/unity-connection/overview/.
To participate in the Unity Connection forum, see the
https://communities.cisco.com/community/developer/collaboration/voicemail.
Troubleshooting
See the following for information on troubleshooting all Connection APIs:
https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/connection/REST-API/APIs_Pages/b_CUC_API_
troubleshooting.html
Cisco Unity Connection Notification Interface (CUNI) API
2
API Overview
Getting Started with CUNI
Page 7
C H A P T E R 2
Cisco Unity Connection Notification Interface
(CUNI) API -- CUNI Event Schema
• Schema Example , on page 3
Schema Example
<?xml version="1.0" encoding="utf-8"?>
<xs:schema xmlns="[http://www.cisco.com"] elementFormDefault="qualified"
targetNamespace="[http://www.cisco.com"] xmlns:xs="[http://www.w3.org/2001/XMLSchema">]
<xs:simpleType name="priorityType">
<xs:restriction base="xs:string">
<xs:enumeration value="Low-Priority" />
<xs:enumeration value="Normal-Priority" />
<xs:enumeration value="Urgent" />
<xs:enumeration value="Unknown-Priority" />
</xs:restriction>
</xs:simpleType>
<xs:simpleType name="eventType">
<xs:restriction base="xs:string">
<xs:enumeration value="MESSAGE_INFO" />
<xs:enumeration value="NEW_MESSAGE" />
<xs:enumeration value="SAVED_MESSAGE" />
<xs:enumeration value="UNREAD_MESSAGE" />
<xs:enumeration value="DELETED_MESSAGE" />
<xs:enumeration value="FAILOVER" />
</xs:restriction>
</xs:simpleType>
<xs:simpleType name="messageType">
<xs:restriction base="xs:string">
<xs:enumeration value="Voice" />
<xs:enumeration value="NDR" />
<xs:enumeration value="DR" />
<xs:enumeration value="RR" />
<xs:enumeration value="Fax" />
<xs:enumeration value="Text" />
<xs:enumeration value="UnknownType" />
</xs:restriction>
</xs:simpleType>
<xs:complexType name="messageInfoType">
<xs:attribute name="messageId" type="xs:string" />
<xs:attribute name="receiveTime" type="xs:string" />
<xs:attribute name="msgType" type="messageType" />
<xs:attribute name="uid" type="xs:integer" />
<xs:attribute name="priority" type="priorityType" />
Cisco Unity Connection Notification Interface (CUNI) API
3
Page 8
<xs:attribute name="sender" type="xs:string" />
<xs:attribute name="callerAni" type="xs:string" />
</xs:complexType>
<xs:element name="messageEvent">
xs:complexType
<xs:sequence minOccurs="1" maxOccurs="unbounded">
<xs:element name="messageInfo" type="messageInfoType" />
</xs:sequence>
<xs:attribute name="subscriptionId" type="xs:string" />
<xs:attribute name="eventType" type="eventType" />
<xs:attribute name="eventTime" type="xs:string" />
<xs:attribute name="mailboxId" type="xs:string" />
<xs:attribute name="displayName" type="xs:string" />
<xs:attribute name="USN" type="xs:integer" />
</xs:complexType>
</xs:element>
</xs:schema>
Cisco Unity Connection Notification Interface (CUNI) API
4
Cisco Unity Connection Notification Interface (CUNI) API -- CUNI Event Schema
Schema Example
Page 9
C H A P T E R 3
Cisco Unity Connection Notification Interface
(CUNI) API -- Subscribing to and Processing
Notification Events
• Subscribing to Notification Events , on page 5
• Processing Notification Events , on page 6
Subscribing to Notification Events
Subscribing to notification events is done through the web service interface, and can be as simple as a single
web service call to "subscribe".
At a minimum you should pass in:
• The callback URL where XML notifications will be posted by the Notifier.
• The date/time when the subscription will expire
It is also possible to pass in a list of the resources (userid) that you are interested in receiving events for,
although that can also be done via a subsequent call to "addResourceIdToSubscription". We recommend that
you leave the eventTypeList empty, indicating that you would like to receive all types of message events.
This example shows making a call to subscribe in Java, using Axis2 stubs generated from the WSDL:
Cisco Unity Connection Notification Interface (CUNI) API
5
Page 10
Calendar expiration = java.util.Calendar.getInstance();
com.cisco.unity.messageeventservice.MessageEventServiceStub.Subscribe s =
new com.cisco.unity.messageeventservice.MessageEventServiceStub.Subscribe();
// Set subscription expiry to two months from now.
expiration.add(Calendar.MONTH, 2);
s.setExpiration(expiration);
// Specify the users we're interested in, which is just the operator for this example.
ArrayOfString resourceList = new ArrayOfString();
resourceList.addString("operator");
s.setResourceIdList(resourceList);
s.setExpiration(expiration);
// Set the callback information - a username and password can be specified, but they are
optional.
MessageEventServiceStub.CallbackServiceInfo c = new
MessageEventServiceStub.CallbackServiceInfo();
c.setCallbackServiceUrl(callbackUrl);
c.setPassword(callbackPassword);
c.setUsername(callbackUserId);
s.setCallbackServiceInfo(c);
// Subscribe!
SubscribeResponse r = stub.subscribe(s);
CUNI Subscriptions will be removed from Cisco Unity Connection server database, if you perform a refresh
upgrade. Make sure to perform re-subscription after successful upgrade of the cluster.
Note
Processing Notification Events
Events will be delivered via HTTP POST to the callback URL that was provided in the call to subscribe.
Cisco Unity Connection Release 12.5(1) SU3 and later, CUNI supports HTTPS for callback URL.
For SSL communication user has the option to choose between Self-signed Certificates and Third Party CA
signed Certificates from Cisco Unified Mobility Advantage server. Make sure to follow below mentioned
steps for Third Party CA signed certificates:
1.
Upload Third Party CA signed certificates in tomcat trust of Unity Connection server.
2.
Restart Tomcat and Notifier services after adding certificates.
Note
Description
Event Type
This event is sent when a new message arrives in the Inbox
folder.
NEW_MESSAGE
This event is sent when a message is marked as read in the
Inbox folder.
SAVED_MESSAGE
Cisco Unity Connection Notification Interface (CUNI) API
6
Cisco Unity Connection Notification Interface (CUNI) API -- Subscribing to and Processing Notification Events
Processing Notification Events
Page 11
Description
Event Type
This event is sent when a message is marked as unread in the
Inbox folder.
UNREAD_MESSAGE
This event is sent when a message is deleted from the Inbox
folder.
DELETED_MESSAGE
This event is sent when a message is hard deleted from the
Deleted folder or from the Inbox folder.
DELETED_MESSAGE_DELETE
This event is sent when a new message arrives in the Deleted
folder.
DELETED_MESSAGE_CREATE
This event is sent when a message is marked as read in the
Deleted folder.
DELETED_MESSAGE_READ
This event is sent when a message is marked as unread in the
Deleted folder.
DELETED_MESSAGE_UNREAD
This event is sent when a message is marked as undeleted
from the Deleted folder
DELETED_MESSAGE_UNDELETE
This event is sent when transcribed message arrives on web
clients.
TRANSCRIPTION_NEW_MESSAGE
Example
This is an example of an event xml. Please note that it is valid to have more than one messageInfo per
messageEvent:
<?xml version="1.0" ?>
<messageEvent subscriptionId="00bdcfd3-159a-48d3-ac7b-2f3b4f83db6c"
eventType="SAVED_MESSAGE"
eventTime="11:15:40 PM 10/30/2008"
mailboxId="abell"
displayName="Alexander Bell"
USN="2265">
<messageInfo messageId="72204bd7-e5c3-446e-adb6-ae5f80db26fb"
receiveTime="04:15:40 PM 10/30/2008"
uid="543"
msgType="Voice"
priority="Normal-Priority"
sender="null"
callerAni="null" />
</messageEvent>
After receiving notifications from CUNI API, if user want to perform messaging operations, then refer "Inbox
Folder Operations" section of "Cisco Unity Connection Messaging Interface (CUMI) API -- Using the CUMI
API" chapter of Cisco Unity Connection Messaging Interface (CUMI) API Guide available at
https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/connection/REST-API/CUMI_API/b_CUMI-API.html
Cisco Unity Connection Notification Interface (CUNI) API
7
Cisco Unity Connection Notification Interface (CUNI) API -- Subscribing to and Processing Notification Events
Processing Notification Events
Page 12
Cisco Unity Connection Notification Interface (CUNI) API
8
Cisco Unity Connection Notification Interface (CUNI) API -- Subscribing to and Processing Notification Events
Processing Notification Events
Page 13
C H A P T E R 4
Cisco Unity Connection Notification Interface
(CUNI) API -- CUNI FAQs
• CUNI FAQs, on page 9
CUNI FAQs
• Where Can I Get the WSDL?
The WSDL can be found at:
http://<connection-server>/messageeventservice/services/MessageEventService?wsdl
The WSDL is the same across versions except that for 8.0 there was a keepAlive
parameter added to the subscribe method.
Note
• What Happens to Subscriptions if the Cisco Unity Connection Server Is Restarted?
Subscriptions are stored in the database. When Cisco Unity Connection is restarted, the Notifier reads
the existing subscriptions and begins sending out notifications.
• What is authentication mechanism to register for CUNI events?
Basic AUTH/HTTPS – requires administrative credentials.
• Can several listeners subscribe for the events for same mailbox specifying different callback urls?
Yes they can
• Does CUNI support HTTPS for subscribing for events as well can a callback url be https?
Yes, Cisco Unity Connection Release 14, 12.5(1) SU3 and later CUNI supports HTTPS for both
subscribing and callback url.
• Does CUNI in HTTPS mode support Multi SAN CA signed certificates configured on callback?
No, CUNI in HTTPS mode only supports self signed and CA signed Certificates.
• What kind of event or alerting mechanism is used in case it cannot reach the callback url? Any
SNMP alert?
Cisco Unity Connection Notification Interface (CUNI) API
9
Page 14
No there are no SNMP alerts generated by the CUNI. There are traces that log information on the Unity
Connection server.
• What happens to events in case of server reboot? Are they queued up and sent to the listeners when
it boots up?
No they are not queued up. They will be lost of a reboot.
• Are subscriptions synchronized between sub and pub? What happens in case one goes down?
Yes they are synchronized so they pub can pick them and take them over.
• Are There Any Unsupported Methods?
Yes. subscribeForAllResources is currently not supported, so users must be listed explicitly. Also there
is no current support for SSL connections for callbacks.
• Can Multiple Subscriptions Use the Same Callback URL?
Not exactly. If Cisco Unity Connection sees a repeat subscription for a callback URL, it will delete the
previous subscription as a safeguard against ending up with unintentional subscriptions.
• Is CUNI a replacement for COMET Notifications?
No. Comet notifications are primarily for sending notifications to browser clients, each representing a
single user. CUNI is not a replacement for comet: it is for server-to-server notifications, whereas Comet
is for server-to-client notifications.
• What is the main use case that CUNI is intended for? What are the advantages over comet?
CUNI is meant for sending message events for multiple users over a single channel, such as in a
server-to-server applications.
• How does CUNI scale for about 20,000 users? Does it have any scale limitations in terms of number
of subscriptions?
CUNI has been tested with several thousand users. Suggestion is for using one limiting per subscription
to 500 user at maximum. Each subscription can register to receive events for multiple users.
• How is the event notification made to the listener, are several events batched and sent at a set
interval or are they sent as they occur?
Notifications are mainly sent as they occur. If a single user has a bunch in rapid succession, they will be
batched.
Cisco Unity Connection Notification Interface (CUNI) API
10
Cisco Unity Connection Notification Interface (CUNI) API -- CUNI FAQs
CUNI FAQs
