C H A P T E R 1
API Oveview
Links to Other API pages: Cisco_Unity_Connection_APIs
• Introduction , on page 1
• Benefits, on page 2
• Technical Details , on page 2
• Getting Started with CUTI , on page 2
• Other CUTI Resources , on page 2
• Troubleshooting , on page 3
Introduction
The Cisco Unity Connection Telephony Interface (CUTI) API is a web service interface for telephone record
and playback on Cisco Unity Connection systems. CUTI is designed to provide a simple, stable method of
accessing telephone record and playback functionality on Connection systems through a standards-based
interface using XML and HTTPS.
You can use CUTI to do the following:
• Initiate dialout to a phone device
• Play and record greetings, messages, and other audio
• Control playback speed and volume
• Stop and resume playback and record
Note: All the above functions associated with CUTI API support both the IPv4 and IPv6 addresses. However,
the IPv6 address works only when Connection platform is configured in Dual (IPv4/IPv6) mode.
For more information see the chapter "Adding or Changing the IPv6 Addresses of Cisco Unity Connection
8.5 and Later Servers" at the following link
http://www.cisco.com/en/US/docs/voice_ip_comm/connection/9x/upgrade/guide/9xcucrug051.html.
Note: With Cisco Unity Connection 9.1(1), the single sign-on feature is enabled for all the Connection Rest
APIs. For more information, see the "Single Sign-On in Cisco Unity Connection" chapter in Security Guide
for Cisco Unity Connection 9.x
http://www.cisco.com/en/US/docs/voice_ip_comm/connection/9x/security/guide/9xcucsec061.html
Cisco Unity Connection Telephony Interface (CUTI) API
1
Page 6
Benefits
With CUTI, you have the ability to record audio as needed by using a phone, providing additional functionality
besides uploading .wav files. You can use CUTI to do the following:
• As part of a User or Admin interface, record audio as part of a name, greeting, or message
• Play secure messages
• Record messages using phone as a media device
Technical Details
CUTI was developed using the latest advances in web-based interfaces: it is a REST interface that standardizes
operations such as add, delete, and modify. The XML comes with standard XML schema definitions that are
annotated with information about what is in them.
As a web-based interface, CUTI is independent of operating system and programming language, and does
not require any client libraries to use.
Getting Started with CUTI
In order to begin developing with the Cisco Unity Connection CUTI API, you will need to obtain the following:
Hardware
• Cisco Media Convergence Server (MCS) for Cisco Unity Connection version 8.0 and later
• For detailed hardware requirements, see the Cisco Unity Connection 8.x Supported Platforms List
Software
• Cisco Unity Connection Software Ordering
• Not for Resale Kits (Must be eligible to purchase)
• Select Unified Communications System Release Kit
Discounts for some of the required hardware and software may be available for participants in the Cisco
Technology Developer Program.
We recommend that all developers have an up-to-date Cisco Developer Services support agreement. This
provides the developer with access to professional support and assistance for application development.
Other CUTI Resources
Additional information about CUTI is also available on the Cisco Developer Network (link to CDN). Note,
however, that the documentation here on the DocWiki is the most up-to-date documentation available for
CUTI.
To participate in the CUTI forum, see the CUTI forum on CDN
Cisco Unity Connection Telephony Interface (CUTI) API
2
API Oveview
Benefits
Page 7
Troubleshooting
See the following for information on troubleshooting all Connection APIs:
Troubleshooting (applies to all Connection APIs)
Cisco Unity Connection Telephony Interface (CUTI) API
3
API Oveview
Troubleshooting
Page 8
Cisco Unity Connection Telephony Interface (CUTI) API
4
API Oveview
Troubleshooting
Page 9
C H A P T E R 2
Cisco Unity Connection Telephony Interface
(CUTI) API -- Using CUTI for Basic Call
Operations
Links to Other API pages: Cisco_Unity_Connection_APIs
• About Basic Call Operations , on page 5
• Playing and Recording by Using a Call , on page 6
• Examples, on page 6
• Play Greetings, on page 14
• Save Video Greetings , on page 18
• Example of Data Fields , on page 19
About Basic Call Operations
The basic call operations are making a call, checking call-connected status, and hanging up. The call object
is used to convey information about a call (see API XSD's). Cisco Unity Connection 10.5(2) and later facilitates
you to make a video call. A user will be able to establish a video call, if all the required pre-checks are satisfied,
which are as follows:
• Mapping video service accounts: subscriber needs a video service configured with the video service
account.
• Enabling Class of Service (COS) Settings for the subscriber
When making a call, the following fields are used:
• number: the only field that does not have a default value. Users with the system administrator role can
call any number, but end users can call only those numbers that do not violate their associated restriction
table, based on their class of service.
• maximumRings: defaults to 4.
• mediaSwitchObjectId: for end users, defaults to the phone system that is associated with the user. For
users who do not have an associated phone system (for example, administrators), the phone system that
is marked as the default TRAP phone system is used.
• calltype: indicates whether the call type is audio or video. If you do not specify the call type, then by
default the call will be placed as an audio call only.
Cisco Unity Connection Telephony Interface (CUTI) API
5
Page 10
When a call has been placed, a client can get server information about the call, most importantly the connected
status.
The following are HTTP commands for basic call operations:
POST http://<server>/calls:
Create a call (make a phone call) by using the information in a call object.
Returns a URI for the new call.
GET http://<server>/calls/<call id>: Get basic call information. Returns a call object.
DELETE http://<server>/calls/<call id>: Hangs up a call.
Playing and Recording by Using a Call
Files on the server can be played and recorded by phone (using the call control operations) by using the
CallControl object (see API XSD's).
Note: Video record and play do not support the pause and resume operations.
Recording or Playing message can be paused and resumed (using the call control operations).The fields of
the CallControl object are described below:
• opType: PLAY, RECORD, PAUSE, RESUME or STOP
• resourceType: MESSAGE, BROADCASTMESSAGE, STREAM, HANDLER, or URI. STREAM is
generally a temporary resource created by a record operation.
• resourceID: Can be a message identifier, a broadcast message identifier or a stream identifier depending
on the resource type.
• Speed, volume and startPosition are all optional parameters. Speed and volume are a percentage and
default to 100. The start position indicates a time in milliseconds and defaults to 0.
• lastResult: The result of the last call control operation.
• folderType: Reserved. Only messages in the inbox can be played.
• sessionId: This is a reference of the video recording on the MediaSense Server using Record API.
MediaSense uniquely identifies the recording using the sessionId.
A call control object is passed to a call by using a POST to the resource URI of the call:
Max time limit for a paused call to be resumed will be idle time out.
Note
POST http://<server>/vmrest/calls/<call id>
Examples
The examples below show how to: make a call, check call status, record by phone, play the recording, pause
and resume the recording, hang up, and send the recording as a message. Each step is shown as the HTTP
request and response.
Make the call
Cisco Unity Connection Telephony Interface (CUTI) API
6
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Playing and Recording by Using a Call
Page 11
POST /vmrest/calls HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic
Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 36
{"number":"2119","maximumRings":"4"}
Response:
HTTP/1.1 201 Created
Set-Cookie:
JSESSIONIDSSO=CB2BE1D9771621DBEA24B479C1A9C10A; Path=/
Set-Cookie:
JSESSIONID=EB7C33B4DC0AAE91CB002D799C8734BA; Path=/vmrest
Location:
[http://cuc-install-67.cisco.com/vmrest/calls/vmrest/calls/1]
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:11 GMT
Server:
Make the Video call
POST https://<connection-server>/vmrest/calls
<Call>
<number>1096</number>
<maximumRings>5</maximumRings>
<callType>Video</callType>
</Call>
The following is the response from the above POST request and the actual response will depend upon the
information given by you:
Response Code: 201
/vmrest/calls/66
CallType:video
JSON Example
POST /vmrest/calls HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic
Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 36
{"number":"1097","maximumRings":"4","callType":"video"}
Cisco Unity Connection Telephony Interface (CUTI) API
7
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Examples
Page 12
Response:
HTTP/1.1 201 Created
Set-Cookie:
JSESSIONIDSSO=CB2BE1D9771621DBEA24B479C1A9C10A; Path=/
Set-Cookie:
JSESSIONID=EB7C33B4DC0AAE91CB002D799C8734BA; Path=/vmrest
Location:
[http://cuc-install-67.cisco.com/vmrest/calls/vmrest/calls/40/calltype:video]
Content-Type: application/json
Video Call Downgrade Scenarios
If a Video call gets downgraded to audio, user receives the following response:
Scenario 1
If a user does not have Video Service Account and try to make a video call, the following response is received:
Response Code: 201
/vmrest/calls/66
CallType: Audio
CallDowngradeReason: Video Service Account does not exist
Scenario 2
If a user does not have Video Service activated on Unity Connection and try to make a video call, the following
response is received:
Response Code: 201
/vmrest/calls/66
CallType: Audio
CallDowngradeReason: Video Service not found
Scenario 3
If a user does not have Video enabled in Class of Service and try to make a video call, the following response
is received:
Response Code: 201
/vmrest/calls/66
CallType: Audio
CallDowngradeReason: Not allowed to Playback and Record Video Greetings
Check call status
GET /vmrest/calls/1 HTTP/1.1
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Response:
Cisco Unity Connection Telephony Interface (CUTI) API
8
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Examples
Page 13
HTTP/1.1 200 OK
Pragma: No-cache
Cache-Control: no-cache
Expires: Wed, 31 Dec 1969 16:00:00 PST
Set-Cookie: JSESSIONIDSSO=849167D3D61D2F30BA278BBF949FDF0F; Path=/
Set-Cookie: JSESSIONID=28A69142E490EC63A56690F9811BDDF9; Path=/vmrest
Content-Type: application/json
{"id":"1","connected":"true","nativeConnectionId":"2"}
Check Video call status
GET https://<connection-server>/vmrest/calls/<call-id>
The following is the response from the above GET request and the actual response will depend upon the
information given by you:
Response Code: 200
<Call>
<number>1007</number>
<id>1105</id>
<connected>true</connected>
<callType>video</callType>
<nativeConnectionId>16</nativeConnectionId>
</Call>
JSON Example
GET /vmrest/calls/1 HTTP/1.1
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Response:
HTTP/1.1 200 OK
Pragma: No-cache
Cache-Control: no-cache
Expires: Wed, 31 Dec 1969 16:00:00 PST
Set-Cookie: JSESSIONIDSSO=849167D3D61D2F30BA278BBF949FDF0F; Path=/
Set-Cookie: JSESSIONID=28A69142E490EC63A56690F9811BDDF9; Path=/vmrest
Content-Type: application/json
{"number":"1097","id":"40","connected":"true","callType":"video","nativeConnectionId":"45"}
Record by phone
POST /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 15
{"op":"RECORD"}
Cisco Unity Connection Telephony Interface (CUTI) API
9
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Examples
Page 14
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=8279B639488165EFFAC8D330FD2A1281; Path=/
Set-Cookie: JSESSIONID=AA008CFCC9B329EA961CD1E660384785; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:13 GMT
Server:
{"op":"RECORD","resourceType":"STREAM","resourceId":"cf1cb014-6394-
4279-ab5a-74a6d680e440.wav",
"lastResult":"0","speed":"100","volume":"100","startPosition":"0"}
Video Recording by phone
POST https://<connection-server>/vmrest/calls/<call-id>
<CallControl>
<op>RECORD</op>
</CallControl>
The following is the response from the above POST request and the actual response will depend upon the
information given by you:
Response Code: 200
<CallControl>
<op>RECORD</op>
<resourceType>STREAM</resourceType>
<resourceId>9d59b180-6147-4796-9488-014ef73203a0.wav</resourceId>
<sessionId>3514637e02b471</sessionId>
<lastResult>0</lastResult>
</CallControl>
JSON Example
POST /vmrest/calls/<call-id> HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 15
{"op":"RECORD"}
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=8279B639488165EFFAC8D330FD2A1281; Path=/
Set-Cookie: JSESSIONID=AA008CFCC9B329EA961CD1E660384785; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:13 GMT
Server:
1({"op":"RECORD","resourceType":"STREAM","resourceId":"a899bac7-9ee2-4c75-b3a7-e6a2a5d6d2dc.wav","sessionId":"1e14628d9a9ac1","lastResult":"0"})
Pause the recording
Cisco Unity Connection Telephony Interface (CUTI) API
10
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Examples
Page 15
POST /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: ucbu-aricent-vm5.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
{"op":"PAUSE"}
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=6A4C99C02E79D696A2DEC46C24A0B2DA; Path=/; Secure
Set-Cookie: JSESSIONID=1E642B010F5AD5630DE922B1378679DF; Path=/vmrest; Secure
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 01 Jun 2012 06:33:49 GMT
Server:
{"op":"PAUSE","lastResult":"0","speed":"100","volume":"100","startPosition":"0"}
Resume the recording
POST /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: ucbu-aricent-vm5.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
{"op":"RESUME"}
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=687E20DEFCC984797342E37A656A1F32; Path=/; Secure
Set-Cookie: JSESSIONID=48D31DBFCBAEF586F2A9398AB11204CC; Path=/vmrest; Secure
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 01 Jun 2012 06:34:25 GMT
Server:
{"op":"RESUME","lastResult":"0","speed":"100","volume":"100","startPosition":"0"}
Play the recording
POST /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 159
{"op":"PLAY","resourceType":"STREAM","resourceId":"cf1cb014-6394-4279-ab5a-74a6d680e440.wav",
"lastResult":"0","speed":"100","volume":"100","startPosition":"0"}
Response:
Cisco Unity Connection Telephony Interface (CUTI) API
11
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Examples
Page 16
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=CD7B1064CEB9385B6FE9279ECBDB40E3; Path=/
Set-Cookie: JSESSIONID=201BD26E840AA2CEEC242A9CCD0FE8F6; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:15 GMT
Server:
{"op":"PLAY","resourceType":"STREAM","resourceId":"cf1cb014-6394-4279-ab5a-74a6d680e440.wav",
"lastResult":"0","speed":"100","volume":"100","startPosition":"0"}
Play Video recording
In a video call,
• For STREAM or URI resource type, if the Session ID is available, then the video recording will be
played, else the audio recording will be played from the Audio resource-ID along with an image.
• For Message or Broadcast Message resource type, the audio recording will be played from the Audio
resource-ID along with an image.
• If both sessionID and resource ID are not available, an error message is send to the user.
POST https://<connection-server>/vmrest/calls/<call-id>
Request:
<CallControl>
<op>PLAY</op>
<resourceType>STREAM</resourceType>
<resourceId>1218f93a-2ce2-4987-9589-f8e06bd54a14.wav</resourceId>
<sessionId>2f61469411d7131</sessionId>
<lastResult>0</lastResult>
</CallControl>
The following is the response from the above POST request and the actual response will depend upon the
information given by you:
Response: 200 Ok
<CallControl>
<op>PLAY</op>
<resourceType>STREAM</resourceType>
<resourceId>1218f93a-2ce2-4987-9589-f8e06bd54a14.wav</resourceId>
<sessionId>2f61469411d7131</sessionId>
<lastResult>0</lastResult>
</CallControl>
JSON Example
Request:
POST /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 159
{"op":"PLAY","resourceType":"STREAM","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav","sessionId":"2f61469411d7131","lastResult":"0"}
Cisco Unity Connection Telephony Interface (CUTI) API
12
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Examples
Page 17
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=CD7B1064CEB9385B6FE9279ECBDB40E3; Path=/
Set-Cookie: JSESSIONID=201BD26E840AA2CEEC242A9CCD0FE8F6; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:15 GMT
Server:
1({"op":"PLAY","resourceType":"STREAM","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav","sessionId":"2f61469411d7131","lastResult":"0"})
Hang up
DELETE /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Accept: text/html, image/gif, image/jpeg, *; q=.2, */*; q=.2
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Response:
HTTP/1.1 204 No Content
Pragma: No-cache
Cache-Control: no-cache
Expires: Wed, 31 Dec 1969 16:00:00 PST
Set-Cookie: JSESSIONIDSSO=93B286C6584533F9EE793A01E5804465; Path=/
Set-Cookie: JSESSIONID=0CCFFFCAD1C11A45EAD1E8F04B22D28D; Path=/vmrest
Date: Fri, 15 Jan 2010 15:14:15 GMT
Server:
Send the recording as a message
POST /vmrest/messages?userobjectid=84c14db9-7439-4326-a2e2-e516aa192dff HTTP/1.1
Content-Type: multipart/form-data;boundary=Boundary_1_16617866_1263568442453
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 731
--Boundary_1_16617866_1263568442453
Content-Type: application/json
{"Subject":"send message test","ArrivalTime":"0","FromSub":"false"}
--Boundary_1_16617866_1263568442453
Content-Type: application/json
{"Recipient":{"Type":"TO","Address":
{"UserGuid":"84c14db9-7439-4326-a2e2-e516aa192dff","DisplayName":"Operator"}
}}
--Boundary_1_16617866_1263568442453
Content-Type: application/xml
<?xml version="1.0" encoding="UTF-8"
standalone="yes"?><CallControl><op>PLAY</op><resourceType>STREAM</resourceType><resourceId>cf1cb014-6394-4279-
ab5a-74a6d680e440.wav</resourceId><lastResult>0</lastResult><speed>100</speed><volume>100</volume><startPosition>0</startPosition></CallControl>
--Boundary_1_16617866_1263568442453--
Response:
Cisco Unity Connection Telephony Interface (CUTI) API
13
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Examples
Page 18
HTTP/1.1 202 Accepted
Set-Cookie: JSESSIONIDSSO=3D875CAE50B6B4947DEDCF5EDA119922; Path=/
Set-Cookie: JSESSIONID=842B1A6E53DAE329F6DA7525951668B4; Path=/vmrest
Content-Type: application/json
Content-Length: 0
Date: Fri, 15 Jan 2010 15:14:16 GMT
Server:
Send the recording as a Video message
POST /vmrest/messages?userobjectid=84c14db9-7439-4326-a2e2-e516aa192dff HTTP/1.1
Content-Type: multipart/form-data;boundary=Boundary_1_16617866_1263568442453
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 731
--Boundary_1_16617866_1263568442453
Content-Type: application/json
{"Subject":"send message test","ArrivalTime":"0","FromSub":"false"}
--Boundary_1_16617866_1263568442453
Content-Type: application/json
{"Recipient":{"Type":"TO","Address":
{"UserGuid":"84c14db9-7439-4326-a2e2-e516aa192dff","DisplayName":"Operator"}
}}
--Boundary_1_16617866_1263568442453
Content-Type: application/xml
<?xml version="1.0" encoding="UTF-8"
standalone="yes"?><CallControl><op>PLAY</op><resourceType>STREAM</resourceType><resourceId>cf1cb014-6394-4279-
ab5a-74a6d680e440.wav</resourceId><sessionId><lastResult>0</lastResult><speed>100</speed><volume>100</volume><startPosition>0</startPosition></CallControl>
--Boundary_1_16617866_1263568442453--
Play Greetings
Play Audio Greetings
Audio Greeting of users, user templates, call handler can be played using CUTI API. a)For a user with mailbox
following should be the request:
Request:
POST https://<connection-server>/vmrest/calls/<call-id>
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
</CallControl>
Cisco Unity Connection Telephony Interface (CUTI) API
14
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Play Greetings
Page 19
Response:
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
<lastResult>0</lastResult>
</CallControl>
Response code:200
Ok
JSON Example
Request
POST /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 159
{"op":"PLAY","resourceType":"HANDLER","resourceId":"0bc5155b-0989-4523-a75a-948cc691b99e.wav","lastResult":"0","speed":"100","volume":"100","startPosition":"0"}
Response: HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=CD7B1064CEB9385B6FE9279ECBDB40E3; Path=/
Set-Cookie: JSESSIONID=201BD26E840AA2CEEC242A9CCD0FE8F6; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:15 GMT
Server:
1({"op":"PLAY","resourceType":"HANDLER","resourceId":"0bc5155b-0989-4523-a75a-948cc691b99e.wav","lastResult":"0","speed":"100","volume":"100","startPosition":"0"}
For a System administrator following should be the request:
In this case greeting of handler whose objectId "handlerObjectId"is passed in request will be played.
POST https://<connection-server>/vmrest/calls/<call-id>?handlerObjectId=<handlerObjectId>
Request:
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
</CallControl>
Response:
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
<lastResult>0</lastResult>
</CallControl>
Response code:200
Ok
Cisco Unity Connection Telephony Interface (CUTI) API
15
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Play Greetings
Page 20
JSON Example
Request:
POST /vmrest/calls/1 ? handlerObjectId=<handlerObjectId>
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 159
{"op":"PLAY","resourceType":"HANDLER","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav"}
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=CD7B1064CEB9385B6FE9279ECBDB40E3; Path=/
Set-Cookie: JSESSIONID=201BD26E840AA2CEEC242A9CCD0FE8F6; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:15 GMT
Server:
1({"op":"PLAY","resourceType":"HANDLER","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav","lastResult":"0","speed":"100","volume":"100","startPosition":"0")
Play Video Greetings
Video greeting of users, user templates, handler can be played using CUTI API. a)For a user with video
account following should be the request:
Request:
POST https://<connection-server>/vmrest/calls/<call-id>
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<sessionId>55d146ced50d1</sessionId>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
<lastResult>0</lastResult>
</CallControl>
Response:
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
<sessionId>55d146ced50d1</sessionId>
<lastResult>0</lastResult>
</CallControl>
Response code:200
Ok
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
16
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Play Greetings
Page 21
Request:
POST /vmrest/calls/1 HTTP/1.1
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 159
{"op":"PLAY","resourceType":"HANDLER","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav","sessionId":"2f61469411d7131"}
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=CD7B1064CEB9385B6FE9279ECBDB40E3; Path=/
Set-Cookie: JSESSIONID=201BD26E840AA2CEEC242A9CCD0FE8F6; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:15 GMT
Server:
1({"op":"PLAY","resourceType":"HANDLER","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav","sessionId":"2f61469411d7131","lastResult":"0"})
For a System administrator following should be the request: In this case video greeting of handler, whose
objectId "handlerObjectId"is passed in request will be played.
POST https://<connection-server>/vmrest/calls/<call-id>?handlerObjectId=<handlerObjectId>
Request:
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<sessionId>55d146ced50d1</sessionId>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
<lastResult>0</lastResult>
</CallControl>
Response:
<CallControl>
<op>PLAY</op>
<resourceType>HANDLER</resourceType>
<resourceId>0bc5155b-0989-4523-a75a-948cc691b99e.wav</resourceId>
<sessionId>55d146ced50d1</sessionId>
<lastResult>0</lastResult>
</CallControl>
Response code:200
Ok
JSON Example
Request:
POST /vmrest/calls/1 ? handlerObjectId=<handlerObjectId>
Content-Type: application/json
Accept: application/json
User-Agent: Java/1.6.0_17
Host: cuc-install-67.cisco.com
Connection: keep-alive
Authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
Content-Length: 159
{"op":"PLAY","resourceType":"HANDLER","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav","sessionId":"2f61469411d7131"}
Cisco Unity Connection Telephony Interface (CUTI) API
17
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Play Greetings
Page 22
Response:
HTTP/1.1 200 OK
Set-Cookie: JSESSIONIDSSO=CD7B1064CEB9385B6FE9279ECBDB40E3; Path=/
Set-Cookie: JSESSIONID=201BD26E840AA2CEEC242A9CCD0FE8F6; Path=/vmrest
Content-Type: application/json
Transfer-Encoding: chunked
Date: Fri, 15 Jan 2010 15:14:15 GMT
Server:
1({"op":"PLAY","resourceType":"HANDLER","resourceId":"1218f93a-2ce2-4987-9589-f8e06bd54a14.wav","sessionId":"2f61469411d7131","lastResult":"0"})
Add new Resource Type: HANDLER in section" Playing and Recording by Using a Call"
Save Video Greetings
Unity Connection allows you to save video greetings using both GET and PUT requests.
Example of GET Request
GET http://<connection-server>/vmrest/handlers/callhandlers/<call handler object
ID>/greetings/<greeting type>/greetingstreamfiles/<language code>/video
The following is the response of the above GET command and the output may vary depending on your inputs.
Response: 200
<CallControl>
<resourceId>aad91d6d-aeca-4a72-8069-b656efb3041f.wav</resourceId>
<sessionId>570146ed1504cb1</sessionId>
</CallControl
JSON Example
Request
GET
vmrest/handlers/callhandlers/30600b21-1a4c-47a3-a078-8078984e5376/greetings/Standard/greetingstreamfiles/1033/video
Accept: application/json
User-Agent: Java/1.6.0_17
Host: <connection-server>
Connection: keep-alive
authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg=
Response
HTTP/1.1 201
Content-Type: application/json
Date: Fri, 15 Jan 2010 15:14:11 GMT
Server:
{ “resourceId” :” aad91d6d-aeca-4a72-8069-b656efb3041f.wav”, “sessionId” : ”570146ed1504cb1”}
Example of PUT Request
PUT http://<connection-server>/vmrest/handlers/callhandlers/<call handler object
ID>/greetings/<greeting type>/greetingstreamfiles/<language code>/video
<CallControl>
<resourceId>aad91d6d-aeca-4a72-8069-b656efb3041f.wav</resourceId>
<sessionId>570146ed1504cb1</sessionId>
</CallControl>
Cisco Unity Connection Telephony Interface (CUTI) API
18
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Save Video Greetings
Page 23
Response: 201 OK
JSON Example
Request
PUT
vmrest/handlers/callhandlers/30600b21-1a4c-47a3-a078-8078984e5376/greetings/Standard/greetingstreamfiles/1033/video
Content-Type: application/json
Accept: application/json
Host: <connection-server>
Connection: keep-alive
authorization: Basic Y2NtYWRtaW5pc3RyYXRvcjplY3NidWxhYg==
{ “resourceId” :” aad91d6d-aeca-4a72-8069-b656efb3041f.wav”, “sessionId” : ”570146ed1504cb1”}
Response :
HTTP/1.1 201
Content-Type: application/json
Date: Fri, 15 Jan 2010 15:14:11 GMT
Server:
Example of Data Fields
Description
Operation
Data
Type
Field Name
The user extension where the caller want to place a call.
Read/Write
Only
Integer
number
The maximum number of phone rings when a call is placed and
if the call is not picked, the caller will get ring-no-answer message.
Default value: 4.
Read/Write
Integer
maximumRings
The unique identifier of the MediaSwitch object that Cisco Unity
Connection uses for placing the call to the subscriber phone.
Read Only
String
mediaSwithObjectid
Displays whether the call type is audio or video.
Read/Write
String
callType
The unique identifier of the call that Cisco Unity Connection uses
for placing the call to the subscriber phone.
Read Only
Integer
callId
Displays whether the subscriber is connected to a call or not.
Read Only
Boolean
connected
The unique identifier of the call created by Unity Connection.
Read Only
Integer
nativeConnectionId
This is a reference of the video recording on the MediaSense
Server using Record API. MediaSense uniquely identifies the
recording using the sessionId.
Read/Write
String
sessionId
Cisco Unity Connection Telephony Interface (CUTI) API
19
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Example of Data Fields
Page 24
Cisco Unity Connection Telephony Interface (CUTI) API
20
Cisco Unity Connection Telephony Interface (CUTI) API -- Using CUTI for Basic Call Operations
Example of Data Fields
Page 25
C H A P T E R 3
Cisco Unity Connection Provisioning Interface
(CUTI) API -- Voice Name Upload for Users
Links to Other API pages: Cisco_Unity_Connection_APIs
• Voice Name Upload for Users, on page 21
Voice Name Upload for Users
This API is used to upload voice name to the Users. There are three ways of uploading the voice name:
• 1. Upload a .wav file from the desktop.
• 2. Record using CUTI(Cisco Unity Telephony Interface) and then upload the recording.
• 3. Pass the .wav file as the input stream to upload the voice name.
Add/Update the Voice Name for Users by Uploading a File from the Desktop
It is a 3 step process:
Step 1
A placeholder for the WAV file must be created with a POST request. This is a temporary file placeholder that can be
used for up to 30 minutes. If it is not used within 30 minutes (assigned to a resource), the file is assumed to be abandoned
and is automatically cleaned.
The request is as follows:
POST https: //<connection-server>/vmrest/voicefiles
Response Code: 201
The content will be the name of the newly created temporary .wav file.
JSON Example
POST https://<connection-sever>/vmrest/voicefiles
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Cisco Unity Connection Telephony Interface (CUTI) API
21
Page 26
Response Code: 201
0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav
Step 2
Use the temporary file name to put the new audio data. The HTTP content type is "audio/wav" and the payload content
is the audio data.
The length of the greeting can be set under the System Settings > General Configuration settings. Here you can
enter the maximum length for system call handler greetings. The range is 1 to 1,200 seconds and default setting
is 90 seconds.
Note
The request is as follows:
PUT https://<connection-server>/vmrest/voicefiles/<temporary file name>
Response Code: 204
The content has been accepted and copied into the temporary file.
JSON Example
POST https://<connection-sever>/vmrest/voicefiles/<temporary file name>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 204
Step 3
Add the file to the voice name. The request is as follows:
PUT https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>
Request Body:
<Distributionlists>
<VoiceName>0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav</VoiceName>
</Distributionlists>
Response Code: 201
JSON Example
POST https://<connection-sever>/vmrest/distributionlists/<distributionlistobjectid>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
{
"VoiceName":"0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav"
}
Response Code: 201
Use the below URL in the browser to listen to the voice name.
https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>/voicename
Cisco Unity Connection Telephony Interface (CUTI) API
22
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Users
Add/Update the Voice Name for Users by Uploading a File from the Desktop
Page 27
Add/Update Voice Name Recording the Greeting using Telephony Interface
It’s a three step process to record a new file then modify the current stream with this new stream
Step 1
Call Connection
In the first step, the integration between Unity Connection and Call Manager must be setup so that a call can be setup.
Refer to the document at the below link to check how to make the call.
http://docwiki.cisco.com/wiki/Cisco_Unity_Connection_Telephony_Interface_(CUTI)_API_--_Using_CUTI_for_Basic_Call_Operations
Step 2
Recording
Once the phone is answered, the second step is to record the greeting. The length of the greeting can be set under the
System Settings > General Configuration settings. Here you can enter the maximum length for system call handler
greetings. The range is 1 to 1,200 seconds and default setting is 90 seconds. The minimum and maximum length of the
recording using telephony integration can be seen in Connection Administration under the Advanced >> Telephony
settings.
• Maximum Recording Time in Milliseconds – default value 1200000
• Minimum Recording Duration in Milliseconds -default value 1000
The same can be fetched using APIs using the following URL:
https://<connection-server>/vmrest/configurationvalues
Check for the values
The request is as follows:
<ConfigurationValue>
<Type>3</Type>
<LastModifiedTime>2013-01-21 07:21:53.49</LastModifiedTime>
<LastModifiedByComponent>CUADMIN</LastModifiedByComponent>
<FullName>System.Telephony.RecordingMinimumLengthMs</FullName>
<Value>1000</Value>
<UserSetting>true</UserSetting>
<MinVal>0</MinVal>
<MaxVal>5000</MaxVal>
<RequiresRestart>false</RequiresRestart>
</ConfigurationValue>
Configuration values can be modified using Connection Administration..
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
23
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Users
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 28
GET https://<connection-server>/vmrest/configurationvalues
Accept : application/json
Connection : keep-alive
{
"@total": "2",
"ConfigurationValue":
[
{
"Type": "1",
"FullName": "System",
"UserSetting": "false"
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
},
{
"Type": "1",
"FullName": "System.Notifier",
"UserSetting": "false",
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
}
]
}
Response Code: 200
Use the following request to record the voice name:
POST https://<connection-server>/vmrest/users/<userobjectId>
Request Body:
<CallControl>
<op>RECORD</op>
</CallControl>
Response Code: 201
Make a note of the output obtained, that will be the input for uploading a wave file.
JSON Example
POST https://<connection-server>/vmrest/ users/<userobjectId>
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD"
}
Response Code: 201
Step 3
Upload the .WAV File
The third step is to upload the wave file to the user handler voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
24
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Users
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 29
PUT https://<connection-server>/vmrest/users/<uerobjectid>/voicename
Request Body:
<CallControl>
<op>RECORD</op>
<resourceType>STREAM</resourceType>
<resourceId>67ed783c-203f-454b-a0e6-57b77820c831.wav</resourceId>
<lastResult>0</lastResult>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
</CallControl>
}
Response Code: 204
JSON Example
POST https://<connection-server>/vmrest/ users/<userobjectid>/voicename
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD",
"resourceType":"STREAM",
"resourceId":"67ed783c-203f-454b-a0e6-57b77820c831.wav",
"lastResult":"0", "speed":"100",
"volume":"100",
"startPosition":"0"
}
Response Code: 204
Use the following URL to listen to the voice name associated with the interview handler: Paste the URL in the browser
and listen to the voice name. https://<connection-server>/vmrest/Users/<userobjectid>/voicename
Adding Voice Name by Passing Input Stream in the Request
The voice name can also be updated using the input stream. An input stream can be created from the .wav
file and passed as the request body. The URL for this should be:
https://<connection-server>/vmrest/users/<userobjectid>/voicename The request body should be like this:
put.setRequestBody(new FileInputStream(file3)); where the PUT request is created to upload the file3 .wav
file. Make sure the content type for the request should be passed as "audio/wav". Use the following URL from
the browser to listen to the voice name associated with the user handler:
https://<connection-server>/vmrest/Users/<userobjectid>/voicename
Cisco Unity Connection Telephony Interface (CUTI) API
25
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Users
Adding Voice Name by Passing Input Stream in the Request
Page 30
Cisco Unity Connection Telephony Interface (CUTI) API
26
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Users
Adding Voice Name by Passing Input Stream in the Request
Page 31
C H A P T E R 4
Cisco Unity Connection Provisioning Interface
(CUTI) API -- Voice Name Upload for Contacts
• Voice Name Upload for Contacts, on page 27
• Add/Update the Voice Name for Contacts by Uploading a File from the Desktop, on page 27
• Add/Update Voice Name Recording the Greeting using Telephony Interface, on page 29
• Adding Voice Name by Passing Input Stream in the Request, on page 31
Voice Name Upload for Contacts
This API is used to upload voice name to the Contacts. There are three ways of uploading the voice name:
• 1. Upload a .wav file from the desktop.
• 2. Record using CUTI(Cisco Unity Telephony Interface) and then upload the recording.
• 3. Pass the .wav file as the input stream to upload the voice name.
Add/Update the Voice Name for Contacts by Uploading a File
from the Desktop
It is a 3 step process:
Step 1
A placeholder for the WAV file must be created with a POST request. This is a temporary file placeholder that can be
used for up to 30 minutes. If it is not used within 30 minutes (assigned to a resource), the file is assumed to be abandoned
and is automatically cleaned.
The request is as follows:
POST https: //<connection-server>/vmrest/voicefiles
Response Code: 201
The content will be the name of the newly created temporary .wav file.
Cisco Unity Connection Telephony Interface (CUTI) API
27
Page 32
JSON Example
POST https://<connection-sever>/vmrest/voicefiles
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 201
0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav
Step 2
Use the temporary file name to put the new audio data. The HTTP content type is "audio/wav" and the payload content
is the audio data.
Rename the .wav file which is to be uploaded as the greeting to the temporary file name generated as part of
the response from step1. For eg : If the file on desktop has name "greeting.wav" and the temporary file name
is 0ad46c53-44eb-4da6-988c- 4f07fabc6bdd.wav(got as part of the response of step1), then the file should be
renamed to 0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav before step 2 is performed. The length of the greeting
can be set under the System Settings > General Configuration settings. Here you can enter the maximum length
for system call handler greetings. The range is 1 to 1,200 seconds and default setting is 90 seconds.
Note
The request is as follows:
PUT https://<connection-server>/vmrest/voicefiles/<temporary file name>
Response Code: 204
JSON Example
POST https://<connection-sever>/vmrest/voicefiles/<temporary file name>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 204
Step 3
Add the file to the voice name. The request is as follows:
PUT https://<connection-server>/vmrest/contacts/<contactobjectid>
Request Body:
<Contacts>
<VoiceName>0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav</VoiceName>
</Contacts>
Response Code: 201
JSON Example
POST https://<connection-sever>/vmrest/contacts/<contactobjectid>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Request Body:
{
"VoiceName":"0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav"
}
Cisco Unity Connection Telephony Interface (CUTI) API
28
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Contacts
Add/Update the Voice Name for Contacts by Uploading a File from the Desktop
Page 33
Response Code: 201
Use the below URL in the browser to listen to the voice name.
https://<connection-server>/vmrest/contacts/<contactobjectid>/voicename
Add/Update Voice Name Recording the Greeting using
Telephony Interface
It’s a three step process to record a new file then modify the current stream with this new stream
Step 1
Call Connection
In the first step, the integration between Unity Connection and Call Manager must be setup so that a call can be setup.
Refer to the document at the below link to check how to make the call.
http://docwiki.cisco.com/wiki/Cisco_Unity_Connection_Telephony_Interface_(CUTI)_API_--_Using_CUTI_for_Basic_Call_Operations
Step 2
Recording
Once the phone is answered, the second step is to record the greeting. The length of the greeting can be set under the
System Settings > General Configuration settings. Here you can enter the maximum length for system call handler
greetings. The range is 1 to 1,200 seconds and default setting is 90 seconds. The minimum and maximum length of the
recording using telephony integration can be seen in Connection Administration under the Advanced >> Telephony
settings.
• Maximum Recording Time in Milliseconds – default value 1200000
• Minimum Recording Duration in Milliseconds -default value 1000
The same can be fetched using APIs using the following URL:
https://<connection-server>/vmrest/configurationvalues
Check for the values
The request is as follows:
<ConfigurationValue>
<Type>3</Type>
<LastModifiedTime>2013-01-21 07:21:53.49</LastModifiedTime>
<LastModifiedByComponent>CUADMIN</LastModifiedByComponent>
<FullName>System.Telephony.RecordingMinimumLengthMs</FullName>
<Value>1000</Value>
<UserSetting>true</UserSetting>
<MinVal>0</MinVal>
<MaxVal>5000</MaxVal>
<RequiresRestart>false</RequiresRestart>
</ConfigurationValue>
Configuration values can be modified using Connection Administration..
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
29
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Contacts
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 34
GET https://<connection-server>/vmrest/configurationvalues
Accept : application/json
Connection : keep-alive
{
"@total": "2",
"ConfigurationValue":
[
{
"Type": "1",
"FullName": "System",
"UserSetting": "false"
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
},
{
"Type": "1",
"FullName": "System.Notifier",
"UserSetting": "false",
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
}
]
}
Use the following request to record the voice name:
POST https://<connection-server>/vmrest/contacts/<contactobjectid>
Request Body:
<CallControl>
<op>RECORD</op>
</CallControl>
Response Code: 201
Make a note of the output obtained, that will be the input for uploading a wave file.
JSON Example
POST https://<connection-server>/vmrest/contacts/<contactobjectid>
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD"
}
Response Code: 201
Step 3
Upload the .WAV File
The third step is to upload the wave file to the contact voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
30
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Contacts
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 35
PUT https://<connection-server>/vmrest/contacts/<Contactobjectid>/voicename
Request Body:
<CallControl>
<op>RECORD</op>
<resourceType>STREAM</resourceType>
<resourceId>67ed783c-203f-454b-a0e6-57b77820c831.wav</resourceId>
<lastResult>0</lastResult>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
</CallControl>
Response Code: 204
JSON Example
POST https://<connection-server>/vmrest/contacts/<contactobjectid>/voicename
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD",
"resourceType":"STREAM",
"resourceId":"67ed783c-203f-454b-a0e6-57b77820c831.wav",
"lastResult":"0", "speed":"100",
"volume":"100",
"startPosition":"0"
}
}
Response Code: 204
Use the following URL to listen to the voice name associated with the interview handler: Paste the URL in the browser
and listen to the voice name. https://<connection-server>/vmrest/Contacts/<contactobjectid>/voicename
Adding Voice Name by Passing Input Stream in the Request
The voice name can also be updated using the input stream. An input stream can be created from the .wav
file and passed as the request body. The URL for this should be:
https://<connection-server>/vmrest/contacts/<contactobjectid>/voicename
The request body should be like this:
put.setRequestBody(new FileInputStream(file3));
where the PUT request is created to upload the file3 .wav file. Make sure the content type for the request
should be passed as "audio/wav". Use the following URL from the browser to listen to the voice name associated
with the contacts:
https://<connection-server>/vmrest/Contacts/<contactobjectid>/voicename
Cisco Unity Connection Telephony Interface (CUTI) API
31
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Contacts
Adding Voice Name by Passing Input Stream in the Request
Page 36
Cisco Unity Connection Telephony Interface (CUTI) API
32
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Contacts
Adding Voice Name by Passing Input Stream in the Request
Page 37
C H A P T E R 5
Cisco Unity Connection Provisioning Interface
(CUTI) API -- Voice Name Upload for Distribution
Lists
Links to Other API pages: Cisco_Unity_Connection_APIs
• Voice Name Upload for Distribution Lists, on page 33
Voice Name Upload for Distribution Lists
This API is used to upload voice name to the distribution lists. There are three ways of uploading the voice
name:
• 1. Upload a .wav file from the desktop.
• 2. Record using CUTI(Cisco Unity Telephony Interface) and then upload the recording.
• 3. Pass the .wav file as the input stream to upload the voice name.
Add/Update the Voice Name for Users by Uploading a File from the Desktop
It is a 3 step process:
Step 1
A placeholder for the WAV file must be created with a POST request. This is a temporary file placeholder that can be
used for up to 30 minutes. If it is not used within 30 minutes (assigned to a resource), the file is assumed to be abandoned
and is automatically cleaned.
The request is as follows:
POST https: //<connection-server>/vmrest/voicefiles
Response Code: 201
The content will be the name of the newly created temporary .wav file.
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
33
Page 38
POST https://<connection-sever>/vmrest/voicefiles
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 201
0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav
Step 2
Use the temporary file name to put the new audio data. The HTTP content type is "audio/wav" and the payload content
is the audio data.
The length of the greeting can be set under the System Settings > General Configuration settings. Here you can
enter the maximum length for system call handler greetings. The range is 1 to 1,200 seconds and default setting
is 90 seconds.
Note
The request is as follows:
PUT https://<connection-server>/vmrest/voicefiles/<temporary file name>
Response Code: 204
The content has been accepted and copied into the temporary file.
JSON Example
POST https://<connection-sever>/vmrest/voicefiles/<temporary file name>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 204
Step 3
Add the file to the voice name. The request is as follows:
PUT https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>
Request Body:
<Distributionlists>
<VoiceName>0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav</VoiceName>
</Distributionlists>
Response Code: 201
JSON Example
POST https://<connection-sever>/vmrest/distributionlists/<distributionlistobjectid>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
{
"VoiceName":"0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav"
}
Response Code: 201
Use the below URL in the browser to listen to the voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
34
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Distribution Lists
Add/Update the Voice Name for Users by Uploading a File from the Desktop
Page 39
https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>/voicename
Add/Update Voice Name Recording the Greeting using Telephony Interface
It’s a three step process to record a new file then modify the current stream with this new stream
Step 1
Call Connection
In the first step, the integration between Unity Connection and Call Manager must be setup so that a call can be setup.
Refer to the document at the below link to check how to make the call.
http://docwiki.cisco.com/wiki/Cisco_Unity_Connection_Telephony_Interface_(CUTI)_API_--_Using_CUTI_for_Basic_Call_Operations
Step 2
Recording
Once the phone is answered, the second step is to record the greeting. The length of the greeting can be set under the
System Settings > General Configuration settings. Here you can enter the maximum length for system call handler
greetings. The range is 1 to 1,200 seconds and default setting is 90 seconds. The minimum and maximum length of the
recording using telephony integration can be seen in Connection Administration under the Advanced >> Telephony
settings.
• Maximum Recording Time in Milliseconds – default value 1200000
• Minimum Recording Duration in Milliseconds -default value 1000
The same can be fetched using APIs using the following URL:
https://<connection-server>/vmrest/configurationvalues
Check for the values
The request is as follows:
<ConfigurationValue>
<Type>3</Type>
<LastModifiedTime>2013-01-21 07:21:53.49</LastModifiedTime>
<LastModifiedByComponent>CUADMIN</LastModifiedByComponent>
<FullName>System.Telephony.RecordingMinimumLengthMs</FullName>
<Value>1000</Value>
<UserSetting>true</UserSetting>
<MinVal>0</MinVal>
<MaxVal>5000</MaxVal>
<RequiresRestart>false</RequiresRestart>
</ConfigurationValue>
Response Code: 200
Configuration values can be modified using Connection Administration..
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
35
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Distribution Lists
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 40
GET https://<connection-server>/vmrest/configurationvalues
Accept : application/json
Connection : keep-alive
{
"@total": "2",
"ConfigurationValue":
[
{
"Type": "1",
"FullName": "System",
"UserSetting": "false"
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
},
{
"Type": "1",
"FullName": "System.Notifier",
"UserSetting": "false",
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
}
]
}
Response Code: 200
Use the following request to record the voice name:
POST https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>
Request Body:
<CallControl>
<op>RECORD</op>
</CallControl>
Response Code: 201
Make a note of the output obtained, that will be the input for uploading a wave file.
JSON Example
POST https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD"
}
Response Code: 201
Step 3
Upload the .WAV File
The third step is to upload the wave file to the distribution list voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
36
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Distribution Lists
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 41
PUT https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>/voicename
Request Body:
<CallControl>
<op>RECORD</op>
<resourceType>STREAM</resourceType>
<resourceId>67ed783c-203f-454b-a0e6-57b77820c831.wav</resourceId>
<lastResult>0</lastResult>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
</CallControl>
Response Code: 204
JSON Example
POST https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>/voicename
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD",
"resourceType":"STREAM",
"resourceId":"67ed783c-203f-454b-a0e6-57b77820c831.wav",
"lastResult":"0", "speed":"100",
"volume":"100",
"startPosition":"0"
}
Response Code: 204
Use the following URL to listen to the voice name associated with the interview handler: Paste the URL in the browser
and listen to the voice name.
https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>/voicename
Adding Voice Name by Passing Input Stream in the Request
The voice name can also be updated using the input stream. An input stream can be created from the .wav
file and passed as the request body. The URL for this should be:
https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>/voicename
The request body should be like this:
put.setRequestBody(new FileInputStream(file3));
where the PUT request is created to upload the file3 .wav file. Make sure the content type for the request
should be passed as "audio/wav". Use the following URL from the browser to listen to the voice name associated
with the distribution list:
https://<connection-server>/vmrest/distributionlists/<distributionlistobjectid>/voicename
Cisco Unity Connection Telephony Interface (CUTI) API
37
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Distribution Lists
Adding Voice Name by Passing Input Stream in the Request
Page 42
Cisco Unity Connection Telephony Interface (CUTI) API
38
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Distribution Lists
Adding Voice Name by Passing Input Stream in the Request
Page 43
C H A P T E R 6
Cisco Unity Connection Provisioning Interface
(CUTI) API -- Voice Name Upload for Call
Handlers
Links to Other API pages: Cisco_Unity_Connection_APIs
• Voice Name Upload for Call Handlers, on page 39
Voice Name Upload for Call Handlers
This API is used to upload voice name to the Call Handlers. There are three ways of uploading the voice
name:
• 1. Upload a .wav file from the desktop.
• 2. Record using CUTI(Cisco Unity Telephony Interface) and then upload the recording.
• 3. Pass the .wav file as the input stream to upload the voice name.
Add/ Update the Voice Name for Call Handler by Uploading a File From the
Desktop
It is a 3 step process:
Step 1
A placeholder for the WAV file must be created with a POST request. This is a temporary file placeholder that can be
used for up to 30 minutes. If it is not used within 30 minutes (assigned to a resource), the file is assumed to be abandoned
and is automatically cleaned.
The request is as follows:
POST https: //<connection-server>/vmrest/voicefiles
Response Code: 201
The content will be the name of the newly created temporary .wav file.
Cisco Unity Connection Telephony Interface (CUTI) API
39
Page 44
JSON Example
POST https://<connection-sever>/vmrest/voicefiles
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 201
0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav
Step 2
Use the temporary file name to put the new audio data. The HTTP content type is "audio/wav" and the payload content
is the audio data.
The length of the greeting can be set under the System Settings > General Configuration settings. Here you can
enter the maximum length for system call handler greetings. The range is 1 to 1,200 seconds and default setting
is 90 seconds.
Note
The request is as follows:
PUT https://<connection-server>/vmrest/voicefiles/<temporary file name>
Response Code: 204
The content has been accepted and copied into the temporary file.
JSON Example
POST https://<connection-sever>/vmrest/voicefiles/<temporary file name>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 204
Step 3
Add the file to the voice name. The request is as follows:
PUT https://<connection-server>/vmrest/handlers/callhandlers/<callhandlerobjectid>
Request Body:
<CallHandler>
<VoiceName>0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav</VoiceName>
</CallHandler>
Response Code: 201
JSON Example
POST https://<connection-sever>/vmrest/handlers/callhandlers/<callhandlerobjectid>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Request Body:
{
"VoiceName":"0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav"
}
Response Code: 201
Cisco Unity Connection Telephony Interface (CUTI) API
40
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Call Handlers
Add/ Update the Voice Name for Call Handler by Uploading a File From the Desktop
Page 45
Use the below URL in the browser to listen to the voice name.
https://<connection-server>/vmrest/handlers/callhandlers/<callhandlerobjectId>/voicename
Add/Update Voice Name Recording the Greeting using Telephony Interface
It’s a three step process to record a new file then modify the current stream with this new stream
Step 1
Call Connection
In the first step, the integration between Unity Connection and Call Manager must be setup so that a call can be setup.
Refer to the document at the below link to check how to make the call.
http://docwiki.cisco.com/wiki/Cisco_Unity_Connection_Telephony_Interface_(CUTI)_API_--_Using_CUTI_for_Basic_Call_Operations
Step 2
Recording
Once the phone is answered, the second step is to record the greeting. The length of the greeting can be set under the
System Settings > General Configuration settings. Here you can enter the maximum length for system call handler
greetings. The range is 1 to 1,200 seconds and default setting is 90 seconds. The minimum and maximum length of the
recording using telephony integration can be seen in Connection Administration under the Advanced >> Telephony
settings.
• Maximum Recording Time in Milliseconds – default value 1200000
• Minimum Recording Duration in Milliseconds -default value 1000
The same can be fetched using APIs using the following URL:
https://<connection-server>/vmrest/configurationvalues
Check for the values
The request is as follows:
<ConfigurationValue>
<Type>3</Type>
<LastModifiedTime>2013-01-21 07:21:53.49</LastModifiedTime>
<LastModifiedByComponent>CUADMIN</LastModifiedByComponent>
<FullName>System.Telephony.RecordingMinimumLengthMs</FullName>
<Value>1000</Value>
<UserSetting>true</UserSetting>
<MinVal>0</MinVal>
<MaxVal>5000</MaxVal>
<RequiresRestart>false</RequiresRestart>
</ConfigurationValue>
Response Code: 200
Configuration values can be modified using Connection Administration..
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
41
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Call Handlers
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 46
GET https://<connection-server>/vmrest/configurationvalues
Accept : application/json
Connection : keep-alive
{
"@total": "2",
"ConfigurationValue":
[
{
"Type": "1",
"FullName": "System",
"UserSetting": "false"
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
},
{
"Type": "1",
"FullName": "System.Notifier",
"UserSetting": "false",
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
}
]
}
Response Code: 200
Use the following request to record the voice name:
POST https://<connection-server>/vmrest/calls/<CallId>
Request Body:
<CallControl>
<op>RECORD</op>
</CallControl>
Response Code: 201
Make a note of the output obtained, that will be the input for uploading a wave file.
JSON Example
POST https://<connection-server>/vmrest/calls/<CallId>
Accept application/json
Content-Type: application/json
Connection: keep-alive
Request Body:
{
"op":"RECORD"
}
Response Code: 201
Step 3
Upload the .WAV File
The third step is to upload the wave file to the call handler voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
42
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Call Handlers
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 47
PUT https://< connection-server>/vmrest/handlers/callhandlers/<callhandlerobjectid>/voicename
Request Body:
<CallControl>
<op>RECORD</op>
<resourceType>STREAM</resourceType>
<resourceId>67ed783c-203f-454b-a0e6-57b77820c831.wav</resourceId>
<lastResult>0</lastResult>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
</CallControl>>
Response Code: 204
JSON Example
POST https://<connection-server>/vmrest/handlers/ callhandlers/<callhandlerobjectid>/voicename
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD",
"resourceType":"STREAM",
"resourceId":"67ed783c-203f-454b-a0e6-57b77820c831.wav",
"lastResult":"0", "speed":"100",
"volume":"100",
"startPosition":"0"
}
Response Code: 204
Use the following URL to listen to the voice name associated with the call handler: Paste the URL in the browser and
listen to the voice name.
https://<connection-server>/vmrest/handlers/callhandlers/<callhandlerobjectid>/voicename
Adding Voice Name by Passing Input Stream in the Request
The voice name can also be updated using the input stream. An input stream can be created from the .wav
file and passed as the request body. The URL for this should be:
https://<connection-server>/vmrest/handlers/callhandlers/<callhandlerobjectid>/voicename
The request body should be like this:
put.setRequestBody(new FileInputStream(file3));
where the PUT request is created to upload the file3 .wav file. Make sure the content type for the request
should be passed as "audio/wav". Use the following URL from the browser to listen to the voice name associated
with the call handler:
https://<connection-server>/vmrest/handlers/callhandlers/<callhandlerobjectid>/voicename
Cisco Unity Connection Telephony Interface (CUTI) API
43
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Call Handlers
Adding Voice Name by Passing Input Stream in the Request
Page 48
Cisco Unity Connection Telephony Interface (CUTI) API
44
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Call Handlers
Adding Voice Name by Passing Input Stream in the Request
Page 49
C H A P T E R 7
Cisco Unity Connection Provisioning Interface
(CUTI) API -- Voice Name Upload for Directory
Handlers
Links to Other API pages: Cisco_Unity_Connection_APIs
• Voice Name Upload for Directory Handlers, on page 45
Voice Name Upload for Directory Handlers
This API is used to upload voice name to the Directory Handler. There are three ways of uploading the voice
name:
• 1. Upload a .wav file from the desktop.
• 2. Record using CUTI(Cisco Unity Telephony Interface) and then upload the recording.
• 3. Pass the .wav file as the input stream to upload the voice name.
Add/Update the Voice Name for Directory Handler by Uploading a File from
the Desktop
It is a 3 step process:
Step 1
A placeholder for the WAV file must be created with a POST request. This is a temporary file placeholder that can be
used for up to 30 minutes. If it is not used within 30 minutes (assigned to a resource), the file is assumed to be abandoned
and is automatically cleaned.
The request is as follows:
POST https: //<connection-server>/vmrest/voicefiles
Response Code: 201
The content will be the name of the newly created temporary .wav file.
Cisco Unity Connection Telephony Interface (CUTI) API
45
Page 50
JSON Example
POST https://<connection-sever>/vmrest/voicefiles
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 201
0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav
Step 2
Use the temporary file name to put the new audio data. The HTTP content type is "audio/wav" and the payload content
is the audio data.
The length of the greeting can be set under the System Settings > General Configuration settings. Here you can
enter the maximum length for system call handler greetings. The range is 1 to 1,200 seconds and default setting
is 90 seconds.
Note
The request is as follows:
PUT https://<connection-server>/vmrest/voicefiles/<temporary file name>
Response Code: 204
The content has been accepted and copied into the temporary file.
JSON Example
POST https://<connection-sever>/vmrest/voicefiles/<temporary file name>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 204
Step 3
Add the file to the voice name. The request is as follows:
PUT https://<connection-server>/vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>
Request Body:
<DirectoryHandler>
<VoiceName>0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav</VoiceName>
</DirectoryHandler>
Response Code: 201
JSON Example
POST https://<connection-sever>/vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Request Body:
{
"VoiceName":"0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav"
}
Response Code: 201
Cisco Unity Connection Telephony Interface (CUTI) API
46
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Directory Handlers
Add/Update the Voice Name for Directory Handler by Uploading a File from the Desktop
Page 51
Use the below URL in the browser to listen to the voice name.
https://<connection-server>/vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>/voicename
Add/Update Voice Name Recording the Greeting using Telephony Interface
It’s a three step process to record a new file then modify the current stream with this new stream
Step 1
Call Connection
In the first step, the integration between Unity Connection and Call Manager must be setup so that a call can be setup.
Refer to the document at the below link to check how to make the call.
http://docwiki.cisco.com/wiki/Cisco_Unity_Connection_Telephony_Interface_(CUTI)_API_--_Using_CUTI_for_Basic_Call_Operations
Step 2
Recording
Once the phone is answered, the second step is to record the greeting. The length of the greeting can be set under the
System Settings > General Configuration settings. Here you can enter the maximum length for system call handler
greetings. The range is 1 to 1,200 seconds and default setting is 90 seconds. The minimum and maximum length of the
recording using telephony integration can be seen in Connection Administration under the Advanced >> Telephony
settings.
• Maximum Recording Time in Milliseconds – default value 1200000
• Minimum Recording Duration in Milliseconds -default value 1000
The same can be fetched using APIs using the following URL:
https://<connection-server>/vmrest/configurationvalues
Check for the values
The request is as follows:
<ConfigurationValue>
<Type>3</Type>
<LastModifiedTime>2013-01-21 07:21:53.49</LastModifiedTime>
<LastModifiedByComponent>CUADMIN</LastModifiedByComponent>
<FullName>System.Telephony.RecordingMinimumLengthMs</FullName>
<Value>1000</Value>
<UserSetting>true</UserSetting>
<MinVal>0</MinVal>
<MaxVal>5000</MaxVal>
<RequiresRestart>false</RequiresRestart>
</ConfigurationValue>
Response Code: 200
Configuration values can be modified using Connection Administration..
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
47
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Directory Handlers
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 52
GET https://<connection-server>/vmrest/configurationvalues
Accept : application/json
Connection : keep-alive
{
"@total": "2",
"ConfigurationValue":
[
{
"Type": "1",
"FullName": "System",
"UserSetting": "false"
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
},
{
"Type": "1",
"FullName": "System.Notifier",
"UserSetting": "false",
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
}
]
}
Response Code: 200
Use the following request to record the voice name:
POST https://<connection-server>/vmrest/calls/<CallId>
Request Body:
<CallControl>
<op>RECORD</op>
</CallControl>
Response Code: 201
Make a note of the output obtained, that will be the input for uploading a wave file.
JSON Example
POST https://<connection-server>/vmrest/calls/<CallId>
Accept application/json
Content-Type: application/json
Connection: keep-alive
Request Body:
{
"op":"RECORD"
}
Response Code: 201
Step 3
Upload the .WAV File
The third step is to upload the wave file to the call handler voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
48
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Directory Handlers
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 53
PUT https://< connectionserver>/
vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>/voicename
Request Body:
<CallControl>
<op>RECORD</op>
<resourceType>STREAM</resourceType>
<resourceId>67ed783c-203f-454b-a0e6-57b77820c831.wav</resourceId>
<lastResult>0</lastResult>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
</CallControl>
Response Code: 204
JSON Example
POST https://<connectionserver>/
vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>/voicename
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD",
"resourceType":"STREAM",
"resourceId":"67ed783c-203f-454b-a0e6-57b77820c831.wav",
"lastResult":"0", "speed":"100",
"volume":"100",
"startPosition":"0"
}
}
Response Code: 204
Use the following URL to listen to the voice name associated with the directory handler: Paste the URL in the browser
and listen to the voice name.
https://<connection-server>/vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>/voicename
Adding Voice Name by Passing Input Stream in the Request
The voice name can also be updated using the input stream. An input stream can be created from the .wav
file and passed as the request body. The URL for this should be:
https://<connection-server>/vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>/voicename The
request body should be like this:
put.setRequestBody(new FileInputStream(file3));
where the PUT request is created to upload the file3 .wav file. Make sure the content type for the request
should be passed as "audio/wav". Use the following URL from the browser to listen to the voice name associated
with the directory handler:
https://<connection-server>/vmrest/handlers/directoryhandlers/<directoryhandlerobjectid>/voicename
Cisco Unity Connection Telephony Interface (CUTI) API
49
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Directory Handlers
Adding Voice Name by Passing Input Stream in the Request
Page 54
Cisco Unity Connection Telephony Interface (CUTI) API
50
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Directory Handlers
Adding Voice Name by Passing Input Stream in the Request
Page 55
C H A P T E R 8
Cisco Unity Connection Provisioning Interface
(CUTI) API -- Voice Name Upload for Interview
Handlers
• Voice Name Upload for Interview Handlers, on page 51
Voice Name Upload for Interview Handlers
This API is used to upload voice name to the Interview Handlers. There are three ways of uploading the voice
name:
• 1. Upload a .wav file from the desktop.
• 2. Record using CUTI(Cisco Unity Telephony Interface) and then upload the recording.
• 3. Pass the .wav file as the input stream to upload the voice name.
Add/Update the Voice Name for Interview Handler by Uploading a File from
the Desktop
It is a 3 step process:
Step 1
A placeholder for the WAV file must be created with a POST request. This is a temporary file placeholder that can be
used for up to 30 minutes. If it is not used within 30 minutes (assigned to a resource), the file is assumed to be abandoned
and is automatically cleaned.
The request is as follows:
POST https: //<connection-server>/vmrest/voicefiles
Response Code: 201
The content will be the name of the newly created temporary .wav file.
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
51
Page 56
POST https://<connection-sever>/vmrest/voicefiles
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 201
0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav
Step 2
Use the temporary file name to put the new audio data. The HTTP content type is "audio/wav" and the payload content
is the audio data.
The length of the greeting can be set under the System Settings > General Configuration settings. Here you can
enter the maximum length for system call handler greetings. The range is 1 to 1,200 seconds and default setting
is 90 seconds.
Note
The request is as follows:
PUT https://<connection-server>/vmrest/voicefiles/<temporary file name>
Response Code: 204
The content has been accepted and copied into the temporary file.
JSON Example
POST https://<connection-sever>/vmrest/voicefiles/<temporary file name>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Response Code: 204
Step 3
Add the file to the voice name. The request is as follows:
PUT https://<connection-server>/vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>
Request Body:
<InterviewHandler>
<VoiceName>0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav</VoiceName>
</InterviewHandler>
Response Code: 201
JSON Example
POST https://<connection-sever>/vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>
Accept: application/json
Content-Type; application/json
Connection: keep-alive
Request Body:
{
"VoiceName":"0ad46c53-44eb-4da6-988c-4f07fabc6bdd.wav"
}
Response Code: 201
Use the below URL in the browser to listen to the voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
52
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Interview Handlers
Add/Update the Voice Name for Interview Handler by Uploading a File from the Desktop
Page 57
https://<connectionserver>/vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>/voicename
Add/Update Voice Name Recording the Greeting using Telephony Interface
It’s a three step process to record a new file then modify the current stream with this new stream
Step 1
Call Connection
In the first step, the integration between Unity Connection and Call Manager must be setup so that a call can be setup.
Refer to the document at the below link to check how to make the call.
http://docwiki.cisco.com/wiki/Cisco_Unity_Connection_Telephony_Interface_(CUTI)_API_--_Using_CUTI_for_Basic_Call_Operations
Step 2
Recording
Once the phone is answered, the second step is to record the greeting. The length of the greeting can be set under the
System Settings > General Configuration settings. Here you can enter the maximum length for system call handler
greetings. The range is 1 to 1,200 seconds and default setting is 90 seconds. The minimum and maximum length of the
recording using telephony integration can be seen in Connection Administration under the Advanced >> Telephony
settings.
• Maximum Recording Time in Milliseconds – default value 1200000
• Minimum Recording Duration in Milliseconds -default value 1000
The same can be fetched using APIs using the following URL:
https://<connection-server>/vmrest/configurationvalues
Check for the values
The request is as follows:
<ConfigurationValue>
<Type>3</Type>
<LastModifiedTime>2013-01-21 07:21:53.49</LastModifiedTime>
<LastModifiedByComponent>CUADMIN</LastModifiedByComponent>
<FullName>System.Telephony.RecordingMinimumLengthMs</FullName>
<Value>1000</Value>
<UserSetting>true</UserSetting>
<MinVal>0</MinVal>
<MaxVal>5000</MaxVal>
<RequiresRestart>false</RequiresRestart>
</ConfigurationValue>
Response Code: 200
Configuration values can be modified using Connection Administration..
JSON Example
Cisco Unity Connection Telephony Interface (CUTI) API
53
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Interview Handlers
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 58
GET https://<connection-server>/vmrest/configurationvalues
Accept : application/json
Connection : keep-alive
{
"@total": "2",
"ConfigurationValue":
[
{
"Type": "1",
"FullName": "System",
"UserSetting": "false"
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
},
{
"Type": "1",
"FullName": "System.Notifier",
"UserSetting": "false",
"MinVal": "0",
"MaxVal": "0",
"RequiresRestart": "false"
}
]
}
Response Code: 200
Use the following request to record the voice name:
POST https://<connection-server>/vmrest/calls/<CallId>
Request Body:
<CallControl>
<op>RECORD</op>
</CallControl>
Response Code: 201
Make a note of the output obtained, that will be the input for uploading a wave file.
JSON Example
POST https://<connection-server>/vmrest/calls/<CallId>
Accept application/json
Content-Type: application/json
Connection: keep-alive
Request Body:
{
"op":"RECORD"
}
Response Code: 201
Step 3
Upload the .WAV File
The third step is to upload the wave file to the call handler voice name.
Cisco Unity Connection Telephony Interface (CUTI) API
54
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Interview Handlers
Add/Update Voice Name Recording the Greeting using Telephony Interface
Page 59
PUT https://< connectionserver>/
vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>/voicename
Request Body:
<CallControl>
<op>RECORD</op>
<resourceType>STREAM</resourceType>
<resourceId>67ed783c-203f-454b-a0e6-57b77820c831.wav</resourceId>
<lastResult>0</lastResult>
<speed>100</speed>
<volume>100</volume>
<startPosition>0</startPosition>
</CallControl>
Response Code: 204
JSON Example
POST https://<connectionserver>/
vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>/voicename
Accept : application/json
Content-Type : application/json
Connection : keep-alive
Request Body:
{
"op":"RECORD",
"resourceType":"STREAM",
"resourceId":"67ed783c-203f-454b-a0e6-57b77820c831.wav",
"lastResult":"0", "speed":"100",
"volume":"100",
"startPosition":"0"
}
Response Code: 204
Use the following URL to listen to the voice name associated with the interview handler: Paste the URL in the browser
and listen to the voice name.
https://<connection-server>/vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>/voicename
Adding Voice Name by Passing Input Stream in the Request
The voice name can also be updated using the input stream. An input stream can be created from the .wav
file and passed as the request body. The URL for this should be:
https://<connection-server>/vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>/voicename
The request body should be like this:
put.setRequestBody(new FileInputStream(file3));
where the PUT request is created to upload the file3 .wav file. Make sure the content type for the request
should be passed as "audio/wav". Use the following URL from the browser to listen to the voice name associated
with the interview handler:
https://<connection-server>/vmrest/handlers/interviewhandlers/<interviewhandlerobjectid>/voicename
Cisco Unity Connection Telephony Interface (CUTI) API
55
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Interview Handlers
Adding Voice Name by Passing Input Stream in the Request
Page 60
Cisco Unity Connection Telephony Interface (CUTI) API
56
Cisco Unity Connection Provisioning Interface (CUTI) API -- Voice Name Upload for Interview Handlers
Adding Voice Name by Passing Input Stream in the Request
