QoS for VoIP Overview
2
QoSVoIP.mif
QoS for VoIP Overview
For VoIP to be a realistic replacement for standard public switched telephone network (PSTN)
telephony services, customers need to receive the same quality of voice transmission they receive with
basic telephone services—meaning consistently high-quality voice transmissions. Like other real-time
applications, VoIP is extremely bandwidth- and delay-sensitive. For VoIP transmissions to be
intelligible to the receiver, voice packets should not be dropped, excessively delayed, or suffer varying
delay (otherwise known as jitter). For example, the following standards must be met:
•
The default G.729 codec requires packet loss far less than 1 percent to avoid audible errors. Ideally,
there should be no packet loss for VoIP.
•
The ITU G.114 specification recommends less than 150 millisecond (ms) one-way end-to-end
delay for high-quality real-time traffic such as voice. (For international calls, one-way delay up to
300 ms is acceptable, especially for satellite transmission. This one-way delay takes propagation
delay into consideration—the time required for the signal to travel the distance.)
•
Jitter buffers (used to compensate for varying delay) further add to the end-to-end delay, and are
usually only effective on delay variations less than 100 ms. Jitter must therefore be minimized.
VoIP can guarantee high-quality voice transmission only if the voice packets, for both the signaling and
audio channel, are given priority over other kinds of network traffic. For VoIP to be deployed so that
users receive an acceptable level of voice quality, VoIP traffic must be guaranteed certain compensating
bandwidth, latency, and jitter requirements. QoS ensures that VoIP voice packets receive the
preferential treatment they require. In general, QoS provides better (and more predictable) network
service by providing the following features:
•
Supporting dedicated bandwidth
•
Improving loss characteristics
•
Avoiding and managing network congestion
•
Shaping network traffic
•
Setting traffic priorities across the network
Quality of Service for Voice over IP discusses various QoS concepts and features that are applicable to
VoIP.
Sufficient Bandwidth
Before you consider applying any of the QoS features discussed in this document, you must first
provision sufficient network bandwidth to support real-time voice traffic. For example, an 80-kbps
G.711 VoIP call (64 kbps payload plus 16-kbps header) will be poor over a 64-kbps link because at least
16 kbps of the packets (which is 20 percent) will be dropped. This example also assumes that no other
traffic is flowing over the link. After you provision sufficient bandwidth for voice traffic, you can take
further steps to guarantee that voice packets have a certain percentage of the total bandwidth and get
priority.
Page 3
Quality of Service for Voice over IP
Packet Classification
3
QoSVoIP.mif
Packet Classification
The basis for providing any QoS lies in the ability of a network device to identify and group specific
packets. This identification process is called packet classification. After a packet has been classified,
the packet needs to be marked by setting designated bits in the IP header. The following sections
describe classification and marking:
•
Packet Classification Overview
•
Voice Dial Peers Classification and Marking Example
•
Committed Access Rate Classification and Marking Example
•
Policy-Based Routing Classification and Marking Example
•
Modular QoS Command-Line Interface Classification and Marking Example
Packet Classification Overview
To guarantee bandwidth for VoIP packets, a network device must be able to identify VoIP packets in all
the IP traffic flowing through it. Network devices use the source and destination IP address in the IP
header or the source and destination User Datagram Protocol (UDP) port numbers in the UDP header
to identify VoIP packets. This identification and grouping process is called classification and it is the
basis for providing any QoS.
Besides the static classification methods involving Layer 3 or Layer 4 header information matching, you
can use a mechanism such as Resource Reservation Protocol (RSVP) for dynamic classification. RSVP
uses H.245 signaling packets to determine which UDP port the voice conversation will use. It then sets
up dynamic access lists to identify VoIP traffic and places the traffic into a reserved queue. RSVP is
discussed later in this document.
Packet classification can be processor-intensive, so it should occur as far out toward the edge of the
network as possible. Because every hop still needs to make a determination on the treatment a packet
should receive, you need to have a simpler, more efficient classification method in the network core.
This simpler classification is achieved through marking or setting the type of service (ToS) byte in the
IP header.
The three most significant bits of the ToS byte are called the IP Precedence bits. Most applications and
vendors currently support setting and recognizing these three bits. Marking is evolving so that the six
most significant bits of the ToS byte, called the Differentiated Services Code Point (DSCP), can be used
to define differentiated services (DS) classes. DSCP is discussed later is this document.
After every hop in the network is able to classify and identify the VoIP packets (either through port
address information or through the ToS byte), those hops can then provide each VoIP packet with the
required QoS. At that point, you can configure special techniques to provide priority queueing to make
sure that large data packets do not interfere with voice data transmission, and to reduce bandwidth
requirements by compressing the 40-byte IP plus UDP plus RTP header to 2 to 4 bytes.
Classification and Marking
Classification is the process of identifying the class or group to which a packet belongs. Network
devices use various match criteria to place traffic into a certain number of classes. Matches are based
on the following criteria:
•
The dial-peer voice voip global configuration command
•
Access list (standard and extended)
Page 4
Quality of Service for Voice over IP
Packet Classification
4
QoSVoIP.mif
•
Protocol (such as URLs, stateful protocols, or Layer 4 protocol)
•
Input port
•
IP Precedence or DSCP
•
Ethernet 802.1p class of service (CoS)
As mentioned, it can be processor-intensive if nodes must repeat classification based on access list
matches. Therefore, nodes should mark packets as soon as they have identified and classified the VoIP
packets. If a node can set the IP Precedence or DSCP bits in the ToS byte of the IP header as soon as it
identifies traffic as being VoIP traffic, then all of the other nodes in the network can classify based on
these bits.
Marking is the process of the node setting one of the following:
•
Three IP Precedence bits in the IP ToS byte
•
Six DSCP bits in the IP ToS byte
•
Three MPLS Experimental (EXP) bits
•
Three Ethernet 802.1p CoS bits
•
One ATM cell loss probability (CLP) bit
In most IP networks, marking IP Precedence or DSCP should be sufficient to identify traffic as VoIP
traffic.
Voice Dial Peers Classification and Marking Example
With Cisco VoIP gateways, you typically use voice dial peers to classify the VoIP packets and mark the
IP Precedence bits. The following configuration example shows how to mark the IP Precedence bits:
Committed Access Rate Classification and Marking Example
Committed access rate (CAR) is an older technique that involves rate-limiting or policing traffic that
matches certain criteria to an upper bound. CAR supports most of the matching mechanisms and allows
IP Precedence or DSCP bits to be set differently depending on whether packets conform to or exceed a
specified rate.
Configuration Example 1: Classification and Marking Using Dial Peers
dial-peer voice 100 voip
destination-pattern 100
session target ipv4:10.10.10.2
ip precedence 5
In this example, any VoIP call that matches the dial-peer voice 100 voip
command will have all of its voice payload packets set with IP Precedence
5—meaning that the three most significant bits of the IP ToS byte are set
to 101.
Page 5
Quality of Service for Voice over IP
Packet Classification
5
QoSVoIP.mif
In general, CAR is more useful for data packets than for voice packets. For example, all data traffic
coming in on an Ethernet interface at less than 1 Mbps can be placed into IP Precedence Class 3, and
any traffic exceeding the 1 Mbps rate can go into Class 1 or be dropped. Other nodes in the network can
then treat the exceeding or nonconforming traffic marked with lower IP Precedence differently. All
voice traffic should conform to the specified rate if it has been provisioned correctly.
The following configuration example shows how to use CAR to classify and mark VoIP packets:
Policy-Based Routing Classification and Marking Example
Policy-based routing (PBR) is another older feature that allows traffic to be routed based on source port
or access list. It also can be used to classify and mark packets. A simple configuration example follows:
Modular QoS Command-Line Interface Classification and Marking Example
The recommended classification and marking method is the Modular QoS Command-Line Interface
(Mod QoS CLI, or MQC) feature, a template-based configuration method that separates the
classification from the policy, allowing multiple QoS features to be configured together for multiple
classes. You use a class map to classify traffic based on various match criteria and a policy map to
Configuration Example 2: Classification and Marking Using CAR
access-list 100 permit udp any any range 16384 32767
access-list 100 permit tcp any any eq 1720
!
interface Ethernet0/0
ip address 10.10.10.1 255.255.255.0
rate-limit input
access-group 100 1000000 8000 8000 conform-action
set-prec-continue 5 exceed-action set-prec-continue 5
In this example, any traffic that matches access list 100 will be set with
IP Precedence 5—meaning that the three most significant bits of the IP
ToS byte are set to 101. Access list 100 here matches the common UDP
ports used by VoIP and the H.323 signaling traffic to TCP port 1720.
Configuration Example 3: Classification and Marking Using PBR
access-list 100 permit udp any any range 16384 32767
access-list 100 permit tcp any any eq 1720
!
route-map classify_mark
match ip address 100
set ip precedence 5
!
interface Ethernet0/0
ip address 10.10.10.1 255.255.255.0
ip policy route-map classify_mark
In this example, any traffic that matches access list 100 will be set with
IP Precedence 5—meaning that the three most significant bits of the IP
ToS byte are set to 101. Access list 100 here matches the common UDP
ports used by VoIP and H.323 signaling traffic to TCP port 1720.
Page 6
Quality of Service for Voice over IP
QoS Queueing Mechanisms
6
QoSVoIP.mif
determine what should happen to each class. Then you apply the policy to incoming or outgoing traffic
on an interface using the service-policy interface configuration command. The following configuration
example shows how to use Modular QoS to classify and mark packets:
QoS Queueing Mechanisms
After all traffic has been placed into QoS classes based on their QoS requirements, you need to provide
bandwidth guarantees and priority servicing through an intelligent output queueing mechanism. This
section describes queueing mechanisms and includes the following subsections:
•
Low Latency Queueing
•
LLQ Configuration Example
•
Other QoS Queueing Mechanisms
Low Latency Queueing
A priority queue is required for VoIP. You can use any queueing mechanism that effectively gives VoIP
high priority, but low latency queueing (LLQ) is recommended because it is flexible and easy to
configure.
The most flexible queueing method that satisfies VoIP requirements is LLQ. LLQ uses the MQC
configuration method to provide priority to certain classes and to provide guaranteed minimum
bandwidth for other classes. During periods of congestion, the priority queue is policed at the
configured rate so that the priority traffic does not monopolize all the available bandwidth. (If the
Configuration Example 4: Classification and Marking Using MQC
access-list 100 permit udp any any range 16384 32767
access-list 100 permit tcp any any eq 1720
!
class-map voip
match access-group 100
!
policy-map mqc
class voip
set ip precedence 5
<<#various other QoS commands>>
class class-default
set ip precedence 0
<<#various other QoS commands>>
!
interface Ethernet0/0
service-policy input mqc
In this example, any traffic that matches access list 100 will be classified
as class voip and set with IP Precedence 5—meaning that the three most
significant bits of the IP TOS byte are set to 101. Access list 100 here
matches the common UDP ports used by VoIP and H.323 signaling traffic
to TCP port 1720. All other traffic is set with IP Precedence 0. The policy
is called mqc and is applied to incoming traffic on Ethernet interface 0/0.
Page 7
Quality of Service for Voice over IP
QoS Queueing Mechanisms
7
QoSVoIP.mif
priority traffic monopolizes the bandwidth, it prevents bandwidth guarantees for other classes from
being met.) If you provision LLQ correctly, the traffic going into the priority queue should never exceed
the configured rate.
LLQ also allows queue depths to be specified to determine when the router should drop packets if too
many packets are waiting in any particular class queue. There is also a class default that is used to
determine treatment of all traffic not classified by a configured class. The class default can be
configured with the fair-queue interface configuration command, which means that each unclassified
flow will be given an approximately equal share of the remaining bandwidth. Figure 1 shows how LLQ
works.
Figure 1
LLQ Operation
In Figure 1, all traffic going out of an interface or subinterface (for Frame Relay and ATM) is first
classified using MQC. There are four classes: one high priority class, two guaranteed bandwidth
classes, and a default class. The priority class traffic is placed into a priority queue and the guaranteed
bandwidth class traffic is placed into reserved queues. The default class traffic can be given a reserved
queue or can be placed in an unreserved default queue where each flow will get an approximately equal
share of the unreserved and available bandwidth. The scheduler services the queues so that the priority
queue traffic is output first unless it exceeds a configured priority bandwidth and this bandwidth is
needed by a reserved queue (that is, there is congestion). The reserved queues are serviced according
to their reserved bandwidth, which the scheduler uses to calculate a weight. The weight is used to
determine how often a reserved queue is serviced and how many bytes are serviced at a time. The
scheduler services are based on the weighted fair queueing (WFQ) algorithm, a discussion of which is
beyond the scope of this document.
If the priority queue fills up because the transmission rate of priority traffic is higher than the configured
priority bandwidth, the packets at the end of the priority queue will be dropped only if no more
unreserved bandwidth is available. None of the reserved queues are restricted to the configured
bandwidth if bandwidth is available. Packets violating the guaranteed bandwidth and priority are
dropped only during periods of congestion. You must therefore provision the priority queue with
enough bandwidth to handle all the VoIP traffic requiring priority servicing.
60595
Classification
Class priority
Priority queue
Class 1
Reserved queue
Class 2
Reserved queue
Class default
Reserved queue
or unreserved
default queue
Scheduler
Output
Page 8
Quality of Service for Voice over IP
QoS Queueing Mechanisms
8
QoSVoIP.mif
LLQ Configuration Example
The following configuration example shows how to configure LLQ:
Configuration Example 5: LLQ
access-list 100 permit udp any any range 16384 32000
access-list 100 permit tcp any any eq 1720
access-list 101 permit tcp any any eq 80
access-list 102 permit tcp any any eq 23
!
class-map voip
match access-group 100
class-map data1
match protocol
class-map data2
match access-group 102
!
policy-map llq
class voip
priority 32
class data1
bandwidth 64
class data2
bandwidth 32
class class-default
fair-queue
!
interface Serial1/0
bandwidth 256
service-policy output llq
In this example, any traffic that matches access list 100 will be classified
as class voip (meaning voice traffic) and given high priority up to 32 kbps.
Access list 100 matches the common UDP ports used by VoIP and H.323
signaling traffic to TCP port 1720. The class data1 command matches
web traffic (TCP port 80 as seen in access list 101) and guarantees 64
kbps; the class data2 command matches Telnet traffic (TCP port 23 as
seen in access list 102) and guarantees 32 kbps. The default class is
configured to give an equal share of the remaining bandwidth to
unclassified flows. The policy is called llq, and it is applied on outgoing
traffic on serial interface 1/0, which has a total bandwidth of 256 kbps.
Note
By default, the total guaranteed bandwidth and
priority bandwidth for all classes should be less than
75 percent of the interface bandwidth. You can
modify this percentage by using the max-reserved
bandwidth interface configuration command.
Page 9
Quality of Service for Voice over IP
QoS Queueing Mechanisms
9
QoSVoIP.mif
Other QoS Queueing Mechanisms
Several other queueing methods are available. For example, Modified Deficit Round Robin (MDRR) is
a queueing mechanism available on the Cisco 12000 series Gigabit Switch Routers (GSRs) that allows
bandwidth guarantees and priority servicing based on IP Precedence, DSCP, and MPLS EXP classes.
MDRR supports one priority queue, seven reserved queues, and one multicast queue.
Once again, VoIP requires priority but there are data applications that cannot be starved and need
bandwidth guarantees. You can use any queueing mechanism that effectively gives VoIP high priority,
but we recommend LLQ.
Table 1 describes some of the available software queueing mechanisms.
Table 1
Software Queueing Mechanisms
Software Queueing
Mechanism
Description
Benefits
Limitations
FIFO
Packets arrive and leave the
queue in exactly the same
order.
Simple configuration and fast
operation.
No priority servicing or
bandwidth guarantees are
possible.
WFQ
A hashing algorithm places
flows into separate queues
where weights are used to
determine how many
packets are serviced at a
time. You define weights by
setting IP Precedence and
DSCP values.
Simple configuration. Default
on links less than 2 Mbps.
No priority servicing or
bandwidth guarantees are
possible.
Custom Queueing (CQ)
Traffic is classified into
multiple queues with
configurable queue limits.
The queue limits are
calculated based on average
packet size, maximum
transmission unit (MTU),
and the percentage of
bandwidth to be allocated.
Queue limits (in number of
bytes) are dequeued for each
queue, therefore providing
the allocated bandwidth
statistically.
Has been available for a few
years and allows approximate
bandwidth allocation for
different queues.
No priority servicing is
possible. Bandwidth
guarantees are approximate,
and there are a limited number
of queues. Configuration is
relatively difficult.
Priority Queueing (PQ)
Traffic is classified into
high, medium, normal, and
low priority queues. The
high priority traffic is
serviced first, then medium
priority traffic, followed by
normal and low priority
traffic.
Has been available for a few
years and provides priority
servicing.
Higher priority traffic can
starve the lower priority
queues of bandwidth. No
bandwidth guarantees are
possible.
Page 10
Quality of Service for Voice over IP
Fragmentation and Interleaving
10
QoSVoIP.mif
Fragmentation and Interleaving
Because VoIP transmissions are extremely delay-sensitive, VoIP packets must be interleaved or inserted
between data packet fragments. This section describes fragmentation and interleaving, and includes the
following subsections:
•
Fragmentation and Interleaving Overview
•
MLP Link Fragmentation and Interleaving Example
•
FRF.12 Fragmentation and Interleaving Example
Fragmentation and Interleaving Overview
Even if queueing is working at its best and prioritizing voice traffic, there are times when the priority
queue is empty and a packet from another class is serviced. Packets from guaranteed bandwidth classes
must be serviced according to their configured weight. If a priority voice packet arrives in the output
queue while these packets are being serviced, the VoIP packet could wait a substantial amount of time
Class-Based WFQ (CBWFQ)
MQC is used to classify
traffic. Classified traffic is
placed into reserved
bandwidth queues or a
default unreserved queue. A
scheduler services the
queues based on weights so
that the bandwidth
guarantees are honored.
Similar to LLQ except that
there is no priority queue.
Simple configuration and
ability to provide bandwidth
guarantees.
No priority servicing is
possible.
Priority Queue WFQ (PQ-WFQ,
also called IP RTP Priority)
A single interface command
is used to provide priority
servicing to all UDP packets
destined to even port
numbers within a specified
range.
Simple, one command
configuration. Provides
priority servicing to RTP
packets.
All other traffic is treated with
WFQ. RTCP traffic is not
prioritized. No guaranteed
bandwidth capability.
LLQ (Previously called
PQ-CBWFQ)
MQC is used to classify
traffic. Classified traffic is
placed into a priority queue,
reserved bandwidth queues,
or a default unreserved
queue. A scheduler services
the queues based on weights
so that the priority traffic is
sent first (up to a certain
policed limit during
congestion) and the
bandwidth guarantees are
met.
Simple configuration. Ability
to provide priority to multiple
classes of traffic and give
upper bounds on priority
bandwidth utilization. You can
also configure bandwidth
guaranteed classes and a
default class.
No mechanism for providing
multiple levels of priority
yet—all priority traffic is sent
through the same priority
queue. Separate priority
classes can have separate
upper priority bandwidth
bounds during congestion, but
sharing of priority queue
between applications may
introduce jitter.
Table 1
Software Queueing Mechanisms (continued)
Software Queueing
Mechanism
Description
Benefits
Limitations
Page 11
Quality of Service for Voice over IP
Fragmentation and Interleaving
11
QoSVoIP.mif
before being sent. If we assume that a VoIP packet will need to wait behind one data packet, and that
the data packet can be, at most, equal in size to the MTU (1500 bytes for serial and 4470 bytes for
high-speed serial interfaces), we can calculate the wait time based on link speed.
For example, for a link speed of 64 kbps and MTU size of 1500 bytes, we have:
Serialization delay = (1500 bytes * 8 bits/byte) / (64,000 bits/sec) = 187.5 ms
Therefore, a VoIP packet may need to wait up to 187.5 ms before it can be sent if it gets delayed behind
a single 1500-byte packet on a 64-kbps link. VoIP packets usually are sent every 20 ms. With an
end-to-end delay budget of 150 ms and strict jitter requirements, a gap of more than 180 ms is
unacceptable.
You need a mechanism that ensures that the size of one transmission unit is less than 10 ms. Any packets
that have more than 10-ms serialization delay need to be fragmented into 10-ms chunks. A 10-ms chunk
or fragment is the number of bytes that can be sent over the link in 10 ms. You can calculate the size by
using the link speed:
Fragmentation size = (0.01 seconds * 64,000 bps) / (8 bits/byte) = 80 bytes
It takes 10 ms to send an 80-byte packet or fragment over a 64-kbps link.
On low speed links where a 10-ms-sized packet is smaller than the MTU, fragmentation is required.
Simple fragmentation is insufficient, though, because if the VoIP packet must wait behind all the
fragments of a single large data packet, the VoIP packet still will be delayed beyond the end-to-end
delay limit. The VoIP packet must be interleaved or inserted in between the data packet fragments.
Figure 2 illustrates fragmentation and interleaving.
Figure 2
VoIP Packet Fragmentation and Interleaving
Serialization Delay = ---------------------------------
Frame Size
Link Speed
214-ms Serialization Delay
for 1500-Byte Frame at 56 kbps
Before
After using LFI Tools
1500-Byte Data Frame
Data
Data
Voice
Data
60-Byte Voice
60060
Page 12
Quality of Service for Voice over IP
Fragmentation and Interleaving
12
QoSVoIP.mif
Table 2 shows recommended fragment sizes for various link speeds based on the 10-ms rule.
Table 2
Link Speed and Fragmentation Size
Note
The packet fragmentation size should never be lower than the VoIP packet size. Also, you
should never fragment VoIP packets—fragmenting VoIP packets can cause numerous call
setup and quality problems.
Three link fragmentation and interleaving (LFI) mechanisms are available. Table 3 lists their benefits
and limitations.
Link Speed (kbps)
Fragmentation Size (Bytes)
56
70
64
80
128
160
256
320
512
640
768
960
1024
1280
1536
1920 (No fragmentation is required if the fragment
size is larger than the link MTU size. For example, for
a T1 link with a 1500-byte MTU, the fragment size is
1920 bytes; therefore, no fragmentation is required.)
Table 3
Link Speed and Fragmentation Size
LFI Mechanism
Description
Benefits
Limitations
MTU Fragmentation with
WFQ
Interface-level command to
change MTU size or IP MTU
size. Used to fragment large IP
packets to specified MTU size.
LFI uses WFQ to interleave
real-time packets in between the
fragments.
Simple configuration.
Fragments are reassembled
only by receiving application;
therefore use of network is
inefficient. Only IP packets
with Don't Fragment (DF) bit
not set can handle
fragmentation well.
Highly-processor intensive.
Not recommended.
Multilink Point-to-Point
Protocol (MLP) Link
Fragmentation and
Interleaving (LFI)
On point-to-point serial links,
MLP must first be configured,
then a fragmentation size must
be set in milliseconds.
Interleaving must also be
enabled on the multilink
interface.
Packets are fragmented on one
end of link and reassembled at
the other. Several links can be
combined to act as a large
virtual pipe.
Only available on links
configured for PPP. Solutions
for PPP over Frame Relay or
PPP over ATM also are
supported in Cisco IOS
Release 12.1(5)T or later
releases.
Page 13
Quality of Service for Voice over IP
Fragmentation and Interleaving
13
QoSVoIP.mif
MLP Link Fragmentation and Interleaving Example
The following configuration example shows how to configure fragmentation and interleaving using
MLP LFI:
Frame Relay
Fragmentation (FRF.12)
On Frame Relay PVCs, the
frame-relay traffic-shaping
interface configuration
command must be enabled and a
fragmentation size set under the
map class.
Packets are fragmented on one
end of PVC and reassembled
at the other.
Only available on Frame Relay
PVCs with the frame-relay
traffic-shaping interface
configuration command
enabled.
Table 3
Link Speed and Fragmentation Size (continued)
LFI Mechanism
Description
Benefits
Limitations
Configuration Example 6: MLP LFI
interface Serial1/0
bandwidth 256
encapsulation ppp
no fair-queue
ppp multilink
multilink-group 1
!
interface Multilink1
ip address 10.1.1.1 255.255.255.252
bandwidth 256
ppp multilink
ppp multilink fragment-delay 10
ppp multilink interleave
multilink-group 1
In this example, MLP LFI is configured with a fragmentation size of 10
ms, which is calculated based on the bandwidth configured for the
multilink interface. Serial interface 1/0 is placed into multilink group 1
and therefore inherits the multilink configuration in the multilink 1
interface.
Page 14
Quality of Service for Voice over IP
Traffic Shaping
14
QoSVoIP.mif
FRF.12 Fragmentation and Interleaving Example
The following configuration example shows how to configure fragmentation and interleaving using
FRF.12:
Traffic Shaping
Traffic shaping is a QoS mechanism used to send traffic in short bursts at a configured transmission rate.
It is most commonly used in Frame Relay environments where the interface clock rate is not the same
as the guaranteed bandwidth or CIR. This section describes traffic shaping and includes the following
subsections:
•
Traffic Shaping Overview
•
Frame Relay Traffic Shaping Example
Traffic Shaping Overview
Frame Relay traffic shaping is the most common traffic shaping application in VoIP environments.
Frame Relay scenarios usually have a hub and spoke network where the hub link speed is higher than
any of the remote link speeds. In some cases, the sum of the remote link speeds is higher than the hub
link speed, causing oversubscription. Without Frame Relay traffic shaping, the hub may try to send at
higher rates than the remotes can receive traffic, causing the Frame Relay network to arbitrarily drop
traffic. However, the remotes could all send at an aggregate rate that is higher than what the hub can
receive, again causing the Frame Relay network to arbitrarily drop traffic. When we refer to the Frame
Relay network, we mean the service provider (SP) network of WAN switches that provide the
end-to-end PVC connectivity. Because the WAN SP cloud has no Layer 3 or above intelligence, it can
Configuration Example 7: Frame Relay Fragmentation (FRF.12) LFI
interface Serial 0/1
no ip address
encapsulation frame-relay
frame-relay traffic-shaping
!
interface Serial 0/1.64 point-to-point
ip address 10.14.96.2 255.255.255.252
frame-relay interface-dlci 128
class voice
!
map-class frame-relay voice
frame-relay cir 256000
frame-relay fragment 320
In this example, Frame Relay traffic shaping is enabled on DLCI 128 and
FRF.12 is configured with a fragmentation size of 320 bytes, which is 10
ms of the committed information rate (CIR). The fragmentation size
should be 10 ms of the lower port speed at the endpoints of the PVC; this
example assumes that the CIR and the lower port speed are the same:
256 kbps.
Page 15
Quality of Service for Voice over IP
Traffic Shaping
15
QoSVoIP.mif
drop VoIP traffic if contracts are violated. Therefore, you need to control transmission rates into a
Frame Relay cloud so that you can control which packets get dropped and which packets receive priority
servicing. Figure 3 shows an example of a typical Frame Relay network without traffic shaping.
Figure 3
Frame Relay Network
Frame Relay Traffic Shaping Example
The following configuration example shows how to configure Frame Relay traffic shaping:
Frame Relay,
ATM
Central
Site
T1
T1
Remote
Sites
Result:
Buffering that will cause delay and,
eventually, dropped packets
128 kbps
256 kbps
512 kbps
768 kbps
60061
Configuration Example 8: Frame Relay Traffic Shaping
interface Serial 0/1
no ip address
encapsulation frame-relay
frame-relay traffic-shaping
!
interface Serial 0/1.64 point-to-point
ip address 10.14.96.2 255.255.255.252
frame-relay interface-dlci 128
class voice
!
map-class frame-relay voice
no frame-relay adaptive-shaping
frame-relay cir 256000
frame-relay bc 2560
frame-relay mincir 256000
In this example, Frame Relay traffic shaping is enabled on the main serial
interface 0/1 and DLCI 128 is placed into a voice shaping class. Map class
voice sets up a CIR of 256000 bps and a committed burst rate (Bc) of 2560
bits. This configuration means that the router will send 2560 bits every
2560/256,000 seconds (10 ms) and queue any excess bursts. The
minimum CIR is set to the same value as CIR, and adaptive shaping is
disabled. The Frame Relay excess burst (Be) value is not set and therefore
defaults to 0, preventing any bursting over CIR. This is the recommended
configuration for traffic shaping when carrying VoIP.
Page 16
Quality of Service for Voice over IP
IP RTP Header Compression
16
QoSVoIP.mif
IP RTP Header Compression
IP RTP header compression reduces the 40 byte IP+UDP+RTP header to 2 to 4 bytes, thereby reducing
the bandwidth required per voice call on point-to-point links. The header is compressed at one end of
the link and decompressed at the other end. Another standard name for this technique is cRTP, which
stands for compressed RTP. Figure 4 shows the functionality of RTP header compression.
Figure 4
RTP Header Compression
To configure IP RTP header compression, you need to configure the ip rtp header-compression
command under the serial interface, or the frame-relay ip rtp header-compression command under
the Frame Relay subinterface. You can also configure the ip rtp compression-connections interface
configuration command to set a maximum number of flows that will be compressed. Because cRTP can
be processor intensive, you need to limit the number of compressed flows to prevent router performance
degradation. Compressed RTP is recommended on low speed links where bandwidth is scarce and there
are few VoIP calls.
IP
20
UDP
RTP IP Data
8
12
5
IP Data
FTP
SOL
1500 Byte -2.3%
256 Byte
-13%
VoIP
Efficiencies
20 Byte
-240%
Payload
Packet Size
Reduction*
*Also -5ms Reduction in
Serialization Delay at 64 kbps
RTP
Compression
Transmit
Queue
Output Hardware
Configured
Queuing
(e.g. WFQ, CQ)
Traffic
Destined
for Interface
Identify RTP
Traffic
Compress
RTP
Traffic
(Video,
Audio,
etc.)
Classify
Non-RTP Traffic
24174
Page 17
Quality of Service for Voice over IP
Differentiated Services for VoIP
17
QoSVoIP.mif
Differentiated Services for VoIP
The Differentiated Services (DS) architecture QoS model provides a scalable mechanism to classify
packets into groups or classes that have similar QoS requirements. This section describes DS and
includes the following subsections:
•
DS and the DSCP (RFC 2474, RFC 2475) Overview
•
Implementing DS for VoIP: Expedited Forwarding PHB (RFC 2598)
•
DSCP Class-Based Marking Configuration Example
DS and the DSCP (RFC 2474, RFC 2475) Overview
The first IP networks were based on the best-effort service model, which meant that delay, jitter, packet
loss, and bandwidth allocation were unpredictable. Today a large number of networks still follow this
best-effort model and do not support enhanced applications that require some sort of service guarantee.
Using the best-effort model, service providers have no means of offering service level agreements
(SLAs) to their customers other than overprovisioning their network to deal with the busiest traffic
hours. Enterprise customers and end users have no way of providing priority treatment or guaranteed
bandwidth for VoIP. Traffic is treated on a simple, FIFO basis with no QoS enforcement.
The first architectural approach to providing end-to-end QoS required that the application signal its QoS
resource requirements (such as bandwidth and guaranteed delay) to the network. In a VoIP scenario,
this architectural approach meant that either the IP telephone or voice gateway needed to make QoS
requests to every hop in the network so that end-to-end resources would be allocated. Every hop needed
to maintain call state information to determine when to release the QoS resources for other calls and
applications, and if enough resources were available, to accept calls with QoS guarantees. This method
is called the Integrated Services QoS model. The most common implementation of Integrated Services
uses Resource Reservation Protocol (RSVP). RSVP has some advantages, such as Call Admission
Control (CAC), where a call can be rerouted by sending an appropriate signal to the originator if the
network does not have the QoS resources available to support it. However, RSVP also suffers from some
scalability issues; RSVP and those issues are discussed later in this document.
The DS architecture is the most widely deployed and supported QoS model today. It provides a scalable
mechanism to classify packets into groups or classes that have similar QoS requirements and then gives
these groups the required treatment at every hop in the network. The scalability comes from the fact that
packets are classified at the edges of the DS “cloud” or region and marked appropriately so that the core
routers in the cloud can provide QoS based simply on the DS class. The six most significant bits of the
IP Type of Service (ToS) byte are used to specify the DS class; the Differentiated Services Code Point
(DSCP) defines these six bits. The remaining two bits in the IP ToS byte are currently unused.
Figure 5 shows how the IP header defines the DS class.
Page 18
Quality of Service for Voice over IP
Differentiated Services for VoIP
18
QoSVoIP.mif
Figure 5
Differentiated Services Field Definition
Differentiated Services is described and defined in the following RFCs:
•
RFC 2474, Definition of the Differentiated Service Field (DS Field)
•
RFC 2475, An Architecture for Differentiated Service
•
RFC 2597, Assured Forwarding PHB Group
•
RFC 2598, An Expedited Forwarding PHB
RFC 2474 proposes a way of interpreting a field that has always been part of an IP packet. As mentioned
previously in this document, the ToS field describes one entire byte (eight bits) of an IP packet.
Precedence refers to the three most significant bits of the ToS byte; that is, [123]45678. (Occasionally
the term ToS is used to refer to the next three bits: 123[456]78; however, in this document, to be
consistent with the original RFC specification for the IP header (RFC 791), ToS refers to the entire set
of eight bits.)
The first three bits of the DSCP are used as class selector bits; the class selector bits makes DSCP
compatible with IP Precedence because IP Precedence uses the same three bits to determine class.
Table 4 shows IP Precedence bit values mapped to DSCP.
Table 4
IP Precedence to DSCP Mapping
The next two bits are used to define drop preference. For example, if the traffic in Class 4 (the first three
bits are 100) exceeds a certain contracted rate, the excess packets could be re-marked so that the drop
preference is raised instead of being dropped. If congestion were to occur in the DS cloud, the first
packets to be dropped would be the “high drop preference” packets. This is similar to DE-bit marking
IP Precedence
IP Precedence Bit
Value
DSCP Bits
DSCP Class
5
101
101000
Expedited Forwarding
4
100
100000
Assured Forwarding 4
3
011
011000
Assured Forwarding 3
2
010
010000
Assured Forwarding 2
1
001
001000
Assured Forwarding 1
0
000
000000
Best Effort
0
Bits:
1
2
3
DSCP
DS-Field
(for IPv4, ToS
octet, and for
IPv6, Traffic
Class octet)
Class
Selector
Code Points
Currently
Unused
DSCP
RFC 2474
CU
4
5
6
7
60062
Page 19
Quality of Service for Voice over IP
Differentiated Services for VoIP
19
QoSVoIP.mif
in Frame Relay and CLP-bit marking in ATM. These mechanisms allow the Layer 2 network to make
intelligent drop decisions for nonconforming traffic during periods of congestion. DS allows similar
operation over an IP network. The sixth bit must be set to 0 to indicate to the network devices that the
classes have been set according to the DS standard.
The DS architecture defines a set of traffic conditioners that are used to limit traffic into a DS region
and place it into appropriate DS classes. Meters, markers, shapers, and droppers are all traffic
conditioners. Meters basically are policers, and class-based policing (which you configure using the
police policy-map configuration command under a class in Modular QoS CLI) is a DS-compliant
implementation of a meter. You can use class-based marking to set the DSCP and class-based shaping
as the shaper. Weighted Random Early Detect (WRED) is a dropper mechanism that is supported, but
you should not invoke WRED on the VoIP class. Per hop behavior (PHB) describes what a DS class
should experience in terms of loss, delay, and jitter. A PHB determines how bandwidth is allocated, how
traffic is restricted, and how packets are dropped during congestion.
Three PHBs are defined in DS based on the forwarding behavior required:
•
Best-effort class—Class selector bits set to 000
•
Assured Forwarding PHB—Class selector bits set to 001, 010, 011, or 100
•
Expedited Forwarding PHB—Class selector bits set to 101
The Assured Forwarding (AF) standard specifies four guaranteed bandwidth classes and describes the
treatment each should receive. It also specifies drop preference levels, resulting in a total of 12 possible
AF classes, as shown in Table 5.
Table 5
Possible Assured Forwarding Classes
You would most likely use Assured Forwarding classes for data traffic that does not require priority
treatment and is largely TCP-based. Expedited Forwarding more closely matches VoIP QoS
requirements.
Implementing DS for VoIP: Expedited Forwarding PHB (RFC 2598)
Expedited Forwarding (EF) is intended for delay-sensitive applications that require guaranteed
bandwidth. An EF marking guarantees priority service by reserving a certain minimum amount of
bandwidth that can be used for high priority traffic. In EF, the egress rate (or configured priority
bandwidth) must be greater than or equal to the sum of the ingress rates, so that there is no congestion
for packets marked EF. You implement EF behavior by using the strict priority queue in low latency
queueing (LLQ). Constant bandwidth is guaranteed for traffic belonging to the EF class, but at the same
time if there is congestion, nonconforming packets exceeding the specified priority rate are dropped to
assure that packets in other queues belonging to different classes are not starved of bandwidth. The
recommended DSCP value for EF is 101110 (46). The first three bits of this EF value correspond to IP
Drop Preference
Levels
Class AF1
Class AF2
Class AF3
Class AF4
Low Drop
Precedence
001010
010010
011010
100010
Medium Drop
Precedence
001100
010100
011100
100100
High Drop
Precedence
001110
010110
011110
100110
Page 20
Quality of Service for Voice over IP
Resource Reservation Protocol
20
QoSVoIP.mif
Precedence 5, which is the recommended ip precedence dial-peer configuration command setting for
VoIP traffic. Therefore, if IP devices in the network can recognize IP Precedence or DSCP for
classification and marking purposes, you can provision end-to-end QoS.
DSCP Class-Based Marking Configuration Example
The DS architecture specifies how to classify, mark, police, and shape traffic entering a DS region and
how to treat different classes at every hop in the DS region. At the DS edge, all IP packets are marked
with the appropriate DSCP so that QoS can be provided based on the DSCP inside the DS region. The
following configuration example shows how to configure DSCP marking at the edge using class-based
marking:
All queueing and other QoS parameters now can be set to match on DSCP in the rest of the DS region.
In the remaining sections of this document, we will match IP Precedence 5 traffic as VoIP and IP
Precedence 3 traffic as HTTP (web traffic), with all other traffic going into the default class. Similarly,
DSCP 46 could be used for VoIP and DSCP 26 for HTTP. We could use several other classification and
marking mechanisms, but to maintain consistency and simplicity, we will use IP Precedence.
Resource Reservation Protocol
Resource Reservation Protocol (RSVP) is an implementation of the Integrated Services architecture for
QoS (RFC 2205). When VoIP was introduced, RSVP was immediately seen as a key component that
would provide admission control and QoS for VoIP flows. However, the way RSVP and H.323 were
previously integrated provided neither admission control nor adequate QoS for voice flows. Several
Configuration Example 9: Class-Based Marking of DSCP
access-list 100 permit udp any any range 16384 32000
access-list 100 permit tcp any any eq 1720
access-list 101 permit tcp any any eq 80
!
class-map voip
match access-group 100
class-map webtraffic
match access-group 101
!
policy-map dscp_marking
class voip
set ip dscp 46 #EF Class
class webtraffic
set ip dscp 26 #AF Class
!
interface Ethernet0/0
service-policy input dscp_marking
In this example, all traffic coming in on Ethernet interface 0/0 is
inspected and classified based on the voip and webtraffic class maps.
The policy-map global configuration command sets the DSCP on
the voip class traffic to 46 (101110 for EF) and the webtraffic class
traffic to 26 (011010 for AF3).
Page 21
Quality of Service for Voice over IP
Resource Reservation Protocol
21
QoSVoIP.mif
enhancements have been made to address these limitations, and RSVP can now be used to implement
CAC and to signal a desired QoS that will provide good quality voice end-to-end, even in the presence
of congestion.
In this section RSVP is described (in general), focusing on a particular subset of platforms, topologies,
and protocols. We also assume that you are using H.323 as the session protocol for a VoIP
gateway-based network. This section includes the following subsections:
•
RSVP Overview
•
RSVP for CAC Overview
•
Deploying CAC Based on RSVP
•
Configuring Local Gateway Resources if CAC Fails
•
Using RSVP with LLQ
•
Deploying RSVP Support for LLQ
RSVP Overview
The initial implementation of RSVP for VoIP had two limitations. The first was that CAC could not be
implemented with RSVP because the reservation process was not synchronized with the voice call
signaling. A call would proceed even if the RSVP reservation had failed or had not been completed. The
second limitation was that a successful RSVP reservation might not provide good voice quality during
periods of network congestion. RSVP created a reserved queue-per-traffic flow within the WFQ system
and relied on that system to guarantee a bounded delay. However, WFQ was unable in some cases to
provide an acceptable bounded delay for voice. RSVP needed to be able to use the priority queue in
LLQ to guarantee a bounded delay that would not affect voice quality. In addition, RSVP was not
supported on ATM or on shaped Frame Relay PVCs.
You should deploy RSVP to improve VoIP QoS only where it can have a positive impact on quality and
functionality. The benefits of using RSVP outweigh the costs (management, overhead, and performance
impact) only where there is limited bandwidth and frequent network congestion. Some IP environments
have enough bandwidth to guarantee the appropriate QoS without needing to implement CAC for every
call.
The following four mechanisms were introduced in Cisco IOS software to handle resource-based CAC:
•
PSTN fallback—This method relies on network probing to measure delay, jitter, and loss to
estimate the potential voice impairment that the call will experience. (The potential impairment is
called the Calculated Planning Impairment Factor (ICPIF) and is explained in ITU-T G.113.) With
this mechanism, you can define several thresholds so that calls are rejected if an IP network is
congested.
•
CAC defined on local gateway resources such as CPU, memory, and number of calls—With this
method, you can configure thresholds that trigger different actions, such as hairpin call, reject call,
or play a message.
•
Bandwidth management via the H.323 gatekeeper—In this method, you can configure a maximum
amount of bandwidth that gatekeepers then allocate to calls.
•
RSVP.
In this document we discuss only the use of RSVP for CAC.
Page 22
Quality of Service for Voice over IP
Resource Reservation Protocol
22
QoSVoIP.mif
RSVP for CAC Overview
Using RSVP for VoIP CAC requires the synchronization of the call setup signaling and the RSVP
signaling. This synchronization guarantees that the called-party phone rings only after the resources for
the call have been reserved. This synchronization also gives voice gateways the control of what action
to take before the call setup moves to the alerting stage if the reservation fails or cannot be completed
within a predefined period of time. A voice call will trigger two RSVP reservations because the
reservation and admission control mechanisms provided by RSVP are unidirectional. Each voice
gateway is responsible for initiating and maintaining one reservation toward the other voice gateway.
CAC for a VoIP call fails if at least one of the reservations fails. Figure 6 shows the sequence of packets
exchanged between the gateways during a call setup if RSVP is used for resource reservation.
Figure 6
Call Setup with RSVP Enabled
In Figure 6, an originating gateway (OGW) initiates a call toward a terminating gateway (TGW). The
originating gateway sends an H.323 SETUP message to the terminating gateway to initiate the call. That
SETUP message carries the QoS that the originating gateway considers acceptable for the call. The
terminating gateway responds with an H.323 CALL PROCEEDING message. Both the originating
gateway and the terminating gateway initiate a reservation request by sending an RSVP PATH message.
The packet flows of both reservations are independent of each other unless one of them fails. The
terminating gateway blocks the call setup process waiting for the reservation results. The terminating
gateway controls the admission decision for the call and needs to be notified that the reservations in
both directions were successful. The terminating gateway discovers that its reservation was successful
when it receives the RSVP RESV message. The terminating gateway detects that the originating
gateway reservation was successful when it receives an RSVP RESV CONFIRMATION message from
the originating gateway. At this point, the terminating gateway lets the call setup continue and sends an
H.323 ALERTING message to the originating gateway once it is notified that the called side is in
SETUP
Call Setup Initiated
OGW TGW
Reservation Initiated
Call Connected
Normal Call
Disconnect Initiated
OGW TGW
Reservation Teardown
Initiated
OGW TGW
Reservation Initiated
OGW TGW
Reservation Teardown
Initiated
OGW Originating Gateway
TGW
Terminating Gateway
H.323 Call Setup Signaling
RSVP Reservation Initiated by TGW
RSVP Reservation Initiated by OGW
OGW
TGW
PATH
RESV
RESV CONFIRMATION
RELEASE COMPLETE
PATH TEAR
PATH TEAR
CALL PROCEEDING
PATH
RESV
ALERTING
PATH TEAR
PATH TEAR
CONNECT
60063
Page 23
Quality of Service for Voice over IP
Resource Reservation Protocol
23
QoSVoIP.mif
alerting state. A normal disconnect is initiated when an H.323 RELEASE COMPLETE message is sent
after the call is connected. At that point, the gateways tear down their reservations by sending RSVP
PATH TEAR and RESV TEAR messages.
If at least one RSVP reservation fails, you can configure a voice gateway to take the following actions:
•
The voice gateway can report the call failure to the user or the switch that delivered the call.
•
The call can be rerouted through another path.
•
The call can be connected with best-effort QoS.
This last behavior is possible because the terminating gateway knows which QoS is acceptable for the
call from its own configuration and the value included by the originating gateway in the H.323 SETUP
message. If the terminating gateway and the originating gateway request a nonbest-effort QoS and at
least one reservation fails, the call will proceed as best-effort only if the originating gateway and the
terminating gateway are willing to accept best-effort service. Call release and call rerouting are possible
if one of the two voice gateways will not accept best-effort service. If you configure the gateway to
reject the call and report the failure, CAS trunks and analog lines generate a fast busy signal. On CCS
PRI trunks, a Q.931 DISCONNECT message with a cause “QoS unavailable” (49) will be generated.
Figure 7 shows the details of a call that is rejected because the reservation initiated from the terminating
gateway failed.
Figure 7
Call Failing RSVP CAC Because of Terminating Gateway Reservation Failure
SETUP
Call Setup Initiated
OGW TGW
Reservation Initiated
Call Disconnect Initiated
OGW TGW
Reservation Initiated
OGW Originating Gateway
TGW
Terminating Gateway
H.323 Call Setup Signaling
RSVP Reservation Initiated by TGW
RSVP Reservation Initiated by OGW
OGW
TGW
PATH
PATH
RESV TEAR
RESV CONFIRMATION
RELEASE COMPLETE
PATH TEAR
CALL PROCEEDING
PATH
RESV
PATH TEAR
PATH TEAR
RESV
OGW TGW
Reservation Teardown
Initiated
OGW TGW
Reservation Teardown
Initiated
60064
Page 24
Quality of Service for Voice over IP
Resource Reservation Protocol
24
QoSVoIP.mif
Deploying CAC Based on RSVP
As already mentioned, you should deploy RSVP to improve VoIP QoS only where it can have a positive
impact on quality and functionality. The benefits of using RSVP outweigh the costs only where
bandwidth is limited. We recommend using Cisco IOS Release 12.1(5)T or a later release if you want
to implement CAC for VoIP using RSVP.
You need to complete the following three basic steps to configure CAC for VoIP calls using RSVP:
•
Enable synchronization between RSVP and the call signaling. (This synchronization is enabled by
default when Cisco IOS Release 12.1(5)T or a later release is running.
•
Configure the voice gateways on both sides of the VoIP dial peers to request a particular QoS via
RSVP.
•
Enable RSVP and specify the maximum bandwidth on all links that are traversed by voice packets
where congestion is likely to occur.
The following configuration example shows how to configure CAC for VoIP calls using RSVP:
Configuration Example 10: Deploying CAC Using RSVP
hostname LongBay
!
isdn switch-type primary-ni
call rsvp-sync
!
controller T1 1/0
framing esf
linecode b8zs
pri-group timeslots 1-24
!
interface Ethernet0/0
ip address 10.0.152.254 255.255.255.0
!
interface Serial0/0
bandwidth 1536
ip address 10.10.1.1 255.255.255.0
encapsulation ppp
ip tcp header-compression iphc-format
ip rtp header-compression iphc-format
ip rsvp bandwidth 1152 24
!
interface Serial1/0:23
no ip address
no logging event link-status
isdn switch-type primary-ni
isdn incoming-voice voice
no cdp enable
!
Page 25
Quality of Service for Voice over IP
Resource Reservation Protocol
25
QoSVoIP.mif
The default dial-peer configuration requests and accepts best-effort QoS for VoIP calls. This translates
to the gateway not initiating an RSVP reservation for the call because IP provides best-effort service by
default. The other two service alternatives are controlled-load or guaranteed-delay QoS. These two
services require RSVP signaling; they are requested using the req-qos dial-peer configuration
command. The acceptable QoS controls how strict or loose the CAC criteria should be; you configure
the acceptable QoS controls by using the acc-qos dial-peer configuration command. We recommend
that you configure the originating gateway and the terminating gateway to request and accept
guaranteed delay.
Sometimes you can configure the implicit dial peer matched on a terminating gateway to request and
accept best-effort QoS. This dial peer takes effect when there is not an explicit dial peer match.
Configuring Local Gateway Resources if CAC Fails
As mentioned earlier, you can configure a voice gateway to take different actions if admission control
fails. The first alternative is to have the gateways signal the user or the switch that delivered the call
with a fast busy signal or a disconnect cause. If the call was delivered to the gateway by an ISDN switch,
you can tune the Q.931 disconnect cause to guarantee that the switch handles calls correctly. A “QoS
unavailable” (49) cause is returned by default when an ISDN call fails CAC because of the requested
and acceptable QoS configured. You can modify this cause with the isdn network-failure-cause
interface configuration command or isdn disconnect-cause interface configuration command. The
current implementation of the isdn network-failure-cause command overrides the value configured
using the isdn disconnect-cause command.
ip route 0.0.0.0 0.0.0.0 10.10.1.2
!
voice-port 1/0:23
!
dial-peer voice 100 pots
destination-pattern 2......
no digit-strip
direct-inward-dial
port 1/0:23
!
dial-peer voice 300 voip
destination-pattern 3......
session target ipv4:10.77.39.129
req-qos guaranteed-delay
acc-qos guaranteed-delay
!
line con 0
line aux 0
line vty 0 4
!
end
This example shows a complete voice gateway configuration that
highlights the commands for configuring CAC using RSVP. The voice
gateway can act as an originating gateway and terminating gateway with
this configuration. We have not prioritized voice signaling in this
example.
Configuration Example 10: Deploying CAC Using RSVP (continued)
Page 26
Quality of Service for Voice over IP
Resource Reservation Protocol
26
QoSVoIP.mif
The following configuration example shows how to configure local gateway resources if CAC fails by
tuning the Q.931 Disconnect Cause:
A second option is to allow the gateway to reroute the call through another path. If the dial peer matched
by the call is part of a hunt group, other dial peers in that group are tried according to the preference
dial-peer configuration command. This allows you to implement different types of call routing on the
gateway that consider QoS across IP networks.
The following configuration example shows how to configure local gateway resources by rerouting calls
on the gateway if CAC fails:
Configuration Example 11: Tuning the O.931 Disconnect Cause
!
interface Serial1/0:23
no ip address
no logging event link-status
isdn switch-type primary-ni
isdn network-failure-cause 42
isdn incoming-voice voice
no cdp enable
!
In this example, the router sends a Q.931 DISCONNECT message with a
“Switching Equipment Congestion” (42) cause when an ISDN call fails
CAC on the VoIP leg.
Configuration Example 12: Call Rerouting on the Gateway
dial-peer voice 100 pots
destination-pattern 2......
no digit-strip
direct-inward-dial
port 1/0:23
!
dial-peer voice 300 voip
preference 0
destination-pattern 3......
session target ipv4:10.77.39.129
req-qos guaranteed-delay
acc-qos guaranteed-delay
!
dial-peer voice 400 voip
preference 2
destination-pattern 3......
session target ipv4:10.23.45.2
req-qos guaranteed-delay
acc-qos guaranteed-delay
!
dial-peer voice 500 pots
preference 5
destination-pattern 3......
no digit-strip
direct-inward-dial
port 1/1:23
!
Page 27
Quality of Service for Voice over IP
Resource Reservation Protocol
27
QoSVoIP.mif
The third possibility, available in Cisco IOS releases later than 12.1(5)T, is to configure the gateways
to proceed with the call even if RSVP reservations fail. This option, however, does not provide a major
improvement over earlier Cisco IOS release functionality. The only benefit it provides is that, in case
of a successful RSVP reservation, the call does not proceed until the reservation is established.
As mentioned earlier, a call can fail admission control if at least one of the two RSVP reservations
needed for the call fails. For each RSVP reservation, admission control is performed on all interfaces
where you have enabled RSVP by using the ip rsvp bandwidth interface configuration command. You
can configure two values with the ip rsvp bandwidth command: the maximum total reserved
bandwidth and the maximum bandwidth per reservation. The maximum total bandwidth is limited by
default to no more than 75 percent of the total bandwidth of the interface. You can modify that limit
with the max-reserved-bandwidth interface configuration command. Exceptions to the maximum total
bandwidth limitation are Frame Relay and ATM PVCs. For Frame Relay PVCs, the maximum
reservable bandwidth is the minimum CIR, or, if not configured, half of the CIR. For ATM PVCs, the
maximum reservable bandwidth is 75 percent of the configured available bit rate output minimum cell
rate, near real-time VBR output-SCR, or real-time VBR average rate, whichever is configured. The total
bandwidth available for RSVP reservations may be lower if you have reserved bandwidth using
CBWFQ or LLQ through MQC. A bandwidth manager makes sure that the interface or the PVC
bandwidth is not oversubscribed during the router operation.
Note
This check is not performed during router configuration.
You should configure the maximum bandwidth per reservation to be no lower than what the codec
requires plus all other protocol overhead except the Layer 2 protocol overhead. Table 6 shows the lowest
values that you can use for different codecs. Remember that these values do not account for the
bandwidth savings introduced by cRTP or voice activity detection (VAD). The actual voice stream may
use less bandwidth, but the system will use the worst-case bandwidth.
This example shows an implementation of call rerouting on the gateway.
Calls to seven-digit numbers starting with digit 3 try two voice gateways
first. Calls are routed through the PSTN via voice port 1/1:23 if the VoIP
calls fails due to CAC or any other reason.
Configuration Example 12: Call Rerouting on the Gateway (continued)
Table 6
Bandwidth Reserved by RSVP per VoIP Call
Codec
Reserved Bandwidth per VoIP Call (kbps)
G711alaw
80
G711ulaw
80
G723ar53
22
G723ar63
23
G723r53
22
G723r63
23
G726r16
32
G726r24
40
G726r32
48
G728
32
Page 28
Quality of Service for Voice over IP
Resource Reservation Protocol
28
QoSVoIP.mif
One consideration when deploying RSVP for VoIP is the impact of resource reservation on the postdial
delay. Implementing VoIP CAC based on RSVP relies on a prompt confirmation or rejection of the
requested reservation. The time taken to reserve resources adds to the postdial delay, which should be
kept as low as possible in most cases. RSVP packets are carried inside IP datagrams and are unreliable
by nature. If an RSVP packet is lost during the initial reservation setup, an RSVP refresh timer must
expire before the lost packet is resent. Because this refresh timer typically is defined in tens of seconds,
a scenario that may add a postdial delay is unacceptable for the user. The call rsvp-sync resv-timer
global configuration command lets you control the maximum amount of time that the terminating
gateway waits for the result of RSVP reservation requests. The default value of this timer is 10 seconds;
you can set it to a value from 1 to 60 seconds according to your expectation of postdial delay.
Using RSVP with LLQ
Flows requesting a particular QoS via RSVP can take advantage of the queueing alternatives available
in LLQ, which has two major components: a strict priority queue (PQ) and a CBWFQ system. Earlier
implementations of RSVP relied on WFQ to meet the QoS requirements for delay-sensitive traffic. A
reserved queue with a low weight was created when the RSVP reservation was installed. However, WFQ
could not meet the delay requirements of voice traffic, and voice calls using RSVP were not able to take
advantage of the PQ available throughout LLQ.
In Cisco IOS Release 12.1(3)T and later releases, a priority profile based on traffic characteristics exists
so that certain flows can take advantage of the strict PQ in LLQ. When a RSVP reservation request is
received on an interface where you have enabled WFQ, the flow traffic specification (TSpec) is
compared against the profile to decide if that flow should take advantage of the PQ or if a queue should
be reserved on the WFQ system. The TSpec is the traffic description carried in RSVP messages. This
traffic description is made in terms of a token bucket (token rate r, plus a bucket size b) and some
additional parameters (peak rate p, minimum policed unit m, and maximum packet size M). The PQ
profile is defined in terms of token rate, bucket size, and an optional peak rate to token rate ratio. Flow
reservations with a TSpec that do not exceed those defined in the PQ profile will use the PQ. Those
flows with a TSpec that exceeds at least one parameter defined in the profile will get a reserved queue
in the WFQ system. The priority profile allows you to classify priority flows based on their traffic
characteristics—not just on the transport protocol and port. Figure 8 shows the LLQ structure for an
interface where traffic is classified into different queues using several methods, including RSVP.
G729br8
24
G729r8
24
GSMEFR
29
GSMFR
30
Table 6
Bandwidth Reserved by RSVP per VoIP Call (continued)
Codec
Reserved Bandwidth per VoIP Call (kbps)
Page 29
Quality of Service for Voice over IP
Resource Reservation Protocol
29
QoSVoIP.mif
Figure 8
RSVP Support for LLQ on Point-to-Point Interfaces
Cisco IOS Release 12.1(5)T introduced RSVP support for LLQ on Frame Relay PVCs. In this case, each
PVC has its own queueing structure with a PQ and a CBWFQ system. At the interface level, a FIFO
queue is set up unless you have enabled FRF.12 fragmentation. In that case, a dual FIFO system is set
up with a high priority queue and a low priority queue. The high priority queue receives the PQ traffic
from all PVCs plus Layer 2 control traffic. The low priority queue receives all other traffic from all
PVCs. Remember that Frame Relay traffic shaping (FRTS) is required for Frame Relay circuits whether
FRF.12 fragmentation is enabled or not. FRTS provides the back-pressure mechanism to detect
congestion per PVC. Support for ATM PVCs is available in Cisco IOS Release 12.2(1)T.
Deploying RSVP Support for LLQ
You enable RSVP support for LLQ by default for voice flows on interfaces where RSVP and WFQ are
enabled. You need not explicitly configure priority queues for voice packets. You can configure a
custom priority queue profile using the ip rsvp pq-profile global configuration command. Configuring
the profile as ip rsvp pq-profile voice-like restores the default behavior. The default priority queue
profile uses a token rate of 12,288 bytes per second (approximately 98 kbps), a bucket size of 592 bytes,
and a peak rate equal to 110 percent of the token rate (13,516 bytes per second or approximately
108 kbps). These parameter values support all possible codec configurations on voice gateways running
IP RTP
Priority
Classification
RSVP
Class
Priority
Class 1
Class 2
Class
Default
Default
Unreserved
Classification
Reserved
Queues
Priority
Queue
Scheduler
Non-Voice
Flow
Voice Flow
Reserved
Queues
Reserved
Queues
Reserved
Queues
60096
Page 30
Quality of Service for Voice over IP
Resource Reservation Protocol
30
QoSVoIP.mif
Cisco IOS software. A Cisco voice gateway configured to reserve resources via RSVP will infer the
correct TSpec exclusively from the codec used on the dial peer. You cannot control TSpec values using
the CLI and no other bandwidth-saving features (such as VAD) are taken into consideration. Some
revisions of Microsoft NetMeeting for Windows 98 and Windows 2000 (which use RSVP) signal a
bucket size in the TSpec that is not compatible with these defaults. This problem affects Microsoft
NetMeeting for calls using codecs that require 32 kbps or more. In those cases, you need to create a
custom profile to match the parameters signaled by Microsoft Windows.
The following configuration example shows how to configure RSVP support for LLQ on a Frame Relay
circuit that has two PVCs:
One of the important implications of RSVP support for LLQ is that it lets you classify voice traffic
based on its traffic characteristics rather than on the transport protocol (UDP) and port number (16384
through 32767). The proper operation of LLQ relies on the assumption that the priority queue is used
only by well-behaved traffic (such as voice) that has a predictable rate and a very low burst size.
Classification based on transport protocol and ports could allow bursty or noncritical traffic into the
Configuration Example 13: RSVP Support for LLQ on Frame Relay PVCs
hostname LongBay
!
isdn switch-type primary-ni
call rsvp-sync
!
interface Serial0/0
bandwidth 1536
no ip address
encapsulation frame-relay
no fair-queue
frame-relay traffic-shaping
!
interface Serial0/0.1 point-to-point
ip address 10.10.1.2 255.255.255.0
frame-relay interface-dlci 16
class VoIPoFR
ip rsvp bandwidth 48 24
!
interface Serial0/0.2 point-to-point
ip address 10.10.2.2 255.255.255.0
frame-relay interface-dlci 17
class VoIPoFRip
rsvp bandwidth 48 24
!
ip rsvp pq-profile voice-like
!
map-class frame-relay VoIPoFR
no frame-relay adaptive-shaping
frame-relay cir 64000
frame-relay bc 640
frame-relay mincir 64000
frame-relay fair-queue
frame-relay fragment 80
!
In this example, WFQ is enabled on the PVCs and disabled on the
physical interface. Each PVC has a priority queue for voice traffic. The
physical interface has the dual-FIFO queue structure. FRTS is enabled
and its parameters are defined in the VoIPoFR map class.
Page 31
Quality of Service for Voice over IP
Resource Reservation Protocol
31
QoSVoIP.mif
priority queue, which might affect the quality of existing voice calls and the performance of the traffic
using the WFQ system. You need to take the effects of bursty or noncritical traffic into account when
you are defining a custom priority queue profile. You should understand all the implications on other
types of traffic—in particular, when the PQ profile could let flows with some degree of burstiness into
the priority queue. RSVP support for LLQ prioritizes voice packets but it does not take care of the voice
signaling. It may not be possible to initiate new calls during periods of heavy congestion due to loss of
signaling packets. To address this situation, you can reserve some amount of bandwidth explicitly for
signaling packets using the MQC. You can also mark RSVP messages for special treatment using the
ip rsvp signaling dscp interface configuration command.
In the following configuration example, voice packets are prioritized using RSVP; and the signaling is
guaranteed a minimum bandwidth during periods of congestion through the MQC:
Configuration Example 14: RSVP Support for LLQ + QoS for Signaling Traffic
hostname LongBay
!
class-map h323
match access-group 101
!
policy-map VOIP_SIG
class h323
set ip dscp 34
bandwidth 96
class class-default
fair-queue
!
isdn switch-type primary-ni
call rsvp-sync
!
controller T1 1/0
framing esf
linecode b8zs
pri-group timeslots 1-24
!
interface Ethernet0/0
ip address 10.0.152.254 255.255.255.0
!
interface Serial0/0
bandwidth 1536
ip address 10.10.1.1 255.255.255.0
encapsulation ppp
ip tcp header-compression iphc-format
ip rtp header-compression iphc-format
service-policy output VOIP_SIG
ip rsvp bandwidth 1152 24
!
interface Serial1/0:23
no ip address
no logging event link-status
isdn switch-type primary-ni
isdn incoming-voice voice
no cdp enable
!
access-list 101 permit tcp any eq 1720 any
access-list 101 permit tcp any any eq 1720
!
voice-port 1/0:23
!
Page 32
Quality of Service for Voice over IP
VoIP QoS over Leased Lines (Using PPP)
32
QoSVoIP.mif
VoIP QoS over Leased Lines (Using PPP)
This section describes how to configure VoIP in a typical network where low speed WAN links are used
to carry both data and voice traffic. It includes the following subsections:
•
VoIP over Leased Line (Using PPP) Scenario
•
VoIP over Leased Line (Using PPP) Recommended Solution
VoIP over Leased Line (Using PPP) Scenario
A typical application of VoIP is for a large corporation to use its existing WAN infrastructure for data
traffic to carry voice calls between its headquarters and its branch offices. Figure 9 shows a typical VoIP
network environment where low speed WAN links are being used to carry both data and voice traffic.
dial-peer voice 100 pots
destination-pattern 2......
no digit-strip
direct-inward-dial
port 1/0:23
!
dial-peer voice 300 voip
destination-pattern 3......
session target ipv4:10.77.39.129
req-qos guaranteed-delay
acc-qos guaranteed-delay
!
line con 0
line aux 0
line vty 0 4
In this example, access list 101 matches H.323 signaling traffic to and from
TCP port 1720. This traffic is placed into class h323, which is guaranteed 96
kbps of bandwidth using LLQ. Voice payload is given priority using the RSVP
configuration.
Configuration Example 14: RSVP Support for LLQ + QoS for Signaling Traffic
Page 33
Quality of Service for Voice over IP
VoIP QoS over Leased Lines (Using PPP)
33
QoSVoIP.mif
Figure 9
Typical VoIP Network Environment
For low speed WAN links that are not well-provisioned to serve voice traffic, problems such as delay,
jitter, and loss become even more pronounced. In this particular network environment, the following
factors can contribute to poor voice quality:
•
Large data packets sent before voice packets introduce long delays.
•
Variable-length data packets sent before voice packets make delays unpredictable, resulting in
jitter.
•
Narrow bandwidth makes the 40-byte combined RTP, UDP, and IP header of a 20-byte VoIP packet
especially wasteful.
•
Narrow bandwidth causes severe delay and loss because the link frequently is congested.
•
Many popular QoS techniques that serve data traffic very well, such as WFQ and RED, are
ineffective for voice applications:
–
If you apply WFQ to both voice and data, as the number of data and voice application flows
increases across the link, flow-based WFQ will allocate less and less bandwidth for each flow.
Unlike the elastic data traffic that adapts to available bandwidth, voice quality becomes
unacceptable after too many drops and too much delay.
Cisco 3640
voice
gateway
Ethernet
switch
Ethernet
switch
Ethernet
switch
Ethernet
switch
Ethernet
switch
Cisco
7206
Ethernet
switch
Voice
gateway
Medium-Sized
Branch Office
Corporate
HQ
Cisco 2611
voice
gateway
Ethernet
switch
Small-Sized
Branch Office
PRI
64K PPP
PRI
PRI
PRI
54741
Page 34
Quality of Service for Voice over IP
VoIP QoS over Leased Lines (Using PPP)
34
QoSVoIP.mif
–
RED is specifically designed for TCP traffic. VoIP rides on top of UDP. Therefore, whenever
possible, voice and data traffic should be classified into separate categories and RED should
be applied to data but not to voice.
In addition, each link and piece of equipment in the VoIP path adds delay to voice packet transmission.
The possibility of voice packet loss also increases as voice traffic travels a longer distance and over
more hops in the network. Low speed WAN connections usually are the weakest links.
VoIP over Leased Line (Using PPP) Recommended Solution
Under normal conditions, network equipment and end stations cannot differentiate between the
requirements of real-time voice packets and standard data traffic. This could result in serious speech
degradation. To ensure voice quality, you must classify data and voice traffic into different categories
and give voice traffic priority handling across a shared data network backbone. Giving voice traffic
priority handling minimizes delays and drops, and whenever possible, gives voice traffic predictable
transmission performance. For PPP links, we recommend the following QoS features:
•
Packet classification through MQC
•
Class-based marking (at the DS edge)
•
Priority handling though LLQ
•
CRTP—Needed only on low speed links with a low number of calls for bandwidth optimization
•
MP LFI—Needed only on low speed links (below 1.2 Mbps) to ensure that one fragment
transmission time is less than 10 ms
Page 35
Quality of Service for Voice over IP
VoIP QoS over Leased Lines (Using PPP)
35
QoSVoIP.mif
The following configuration example shows a complete configuration with all of the listed QoS features
enabled:
Configuration Example 15: QoS for VoIP over PPP WAN Links
Commands
Description
class-map voip
match ip precedence 5
!
Creates the class voip for voice traffic that has been
marked with IP Precedence 5 using one of the available
marking methods.
class-map webtraffic
match ip precedence 3
!
Creates the class webtraffic for web traffic that has been
marked with IP Precedence 3 using one of the available
marking methods.
policy-map llq
class voip
priority 64
class webtraffic
bandwidth 64
class class-default
fair-queue
!
Defines the QoS policy map llq: Class voip traffic gets
priority and is limited to 64 kbps during congestion; class
webtraffic packets are guaranteed 64 kbps. All other
traffic shares the remaining bandwidth.
interface Serial1/0
bandwidth 256
encapsulation ppp
no fair-queue
ppp multilink
multilink-group 1
!
Attaches the serial interface 1/0 to multilink interface in
group 1. (For link bandwidths over 1.2 Mbps, Multilink
PPP LFI and cRTP are not needed. In that case, the IP
address and service-policy statement would go under the
serial interface configuration.)
interface Multilink1
ip address 10.1.1.1 255.255.255.252
bandwidth 256
!
Configures Multilink PPP LFI for links less than
1.2 Mbps.
ip rtp header-compression iphc-format
ip tcp header-compression iphc-format
!
Configures cRTP to reduce bandwidth requirements of
each voice call.
ppp multilink
ppp multilink fragment-delay 10
Enables a fragmentation size of 10 ms.
ppp multilink interleave
Enables packet and fragment interleaving.
multilink-group 1
service-policy output llq
!
Attaches the multilink interface to group 1. Attaches the
llq QoS policy to outgoing traffic on the multilink
interface.
In this example, Multilink PPP LFI prevents VoIP packets from getting delayed behind large data packets, cRTP
reduces VoIP bandwidth requirements, and LLQ provides priority to VoIP traffic and guaranteed bandwidth to
another class. You need to configure these features on both ends of the PPP link. Multilink PPP LFI is needed only
for links less than 1.2 Mbps, and cRTP is recommended only on links with a low number of VoIP calls and if the
CPU is not running too high.
Page 36
Quality of Service for Voice over IP
VoIP QoS over Frame Relay Networks
36
QoSVoIP.mif
VoIP QoS over Frame Relay Networks
This section describes how to configure VoIP in a typical network where Frame Relay WAN links are
used to carry voice traffic. It includes the following subsections:
•
VoIP QoS over Frame Relay Scenario
•
VoIP QoS over Frame Relay Recommended Solution
VoIP QoS over Frame Relay Scenario
Another typical VoIP application is for a large corporation to use its existing Frame Relay WAN data
traffic infrastructure to carry voice calls between its headquarters and its branch offices. There are two
options here: either carry the voice and data on separate PVCs or use the same PVC for voice and data
traffic. In the first scenario, you must still give the voice traffic priority by using a technique such as
PVC Interface Priority Queue (PIPQ). PIPQ lets you assign different priorities for PVCs—high,
medium, normal, or low. PIPQ also allows PVCs to be queued at the main physical interface so that high
priority traffic goes before medium, normal, and low priority traffic. PIPQ, however, has the same
problem as priority queueing—the high priority traffic can starve the other traffic of bandwidth.
However, if you use Frame Relay traffic shaping correctly, you can minimize this problem because each
PVC will have a defined maximum transmission rate.
In the most common scenario, you use a single PVC to carry all the traffic between sites, as shown in
Figure 10.
Page 37
Quality of Service for Voice over IP
VoIP QoS over Frame Relay Networks
37
QoSVoIP.mif
Figure 10
VoIP QoS over Low Speed Frame Relay Links
VoIP QoS over Frame Relay Recommended Solution
You need to configure Frame Relay traffic shaping to ensure that speed mismatches at the remote and
hub sites are handled correctly. For example, if the hub site has a T1 connection into the Frame Relay
network and the remote site has a 128-kbps access speed, the hub site has the capability to send at T1
speeds toward this single remote. The Frame Relay switches will buffer this traffic to a small extent, but
then arbitrarily drop anything over 128 kbps. You need to decide what should be dropped and what
should be prioritized at the endpoints of the PVC.
Frame Relay traffic shaping allows the routers to send traffic into the Frame Relay cloud below a
preconfigured rate. Any traffic over this rate is queued, and a queueing algorithm such as LLQ can be
used to make intelligent decisions on which packets should be sent. If the queues fill up, the packets
simply will be dropped. However, if VoIP is given priority, and the total VoIP traffic is below the
traffic-shaping rate, VoIP packets will be serviced with low latency and will not be dropped.
For lower speed links less than 1.2 Mbps, you need to configure packet fragmentation to ensure that a
VoIP packet need not wait behind a large packet. Fragmenting larger data packets to 10 ms of the link
speed can bind the maximum waiting period. You can use cRTP to efficiently use bandwidth if the
number of calls is not too large.
Cisco 3640
voice
gateway
Ethernet
switch
Ethernet
switch
Ethernet
switch
Ethernet
switch
Ethernet
switch
Cisco
7206
Voice
gateway
Medium-Sized
Branch Office
Corporate
HQ
Cisco 2611
voice
gateway
Ethernet
switch
Small-Sized
Branch Office
PRI
Frame Relay PVC
Frame
Relay
switch
Frame Relay PVC
Frame Relay PVC
PRI
PRI
PRI
54742
Page 38
Quality of Service for Voice over IP
VoIP QoS over Frame Relay Networks
38
QoSVoIP.mif
To provide high quality to VoIP over Frame Relay, you need to configure the following features:
•
Frame Relay traffic shaping:
–
Set the frame-relay cir map-class configuration command to maximum transmit rate (it should
be the negotiated guaranteed rate from the service provider).
–
Disable the frame-relay adaptive-shaping map-class configuration command and set the
mincir command value to match the cir command value for best quality voice.
–
Set the frame-relay bc map-class configuration command to 1/100 of CIR to allow traffic
shaping to service packets at least every 10 ms.
•
FRF.12 LFI—You need LFI only if the remote or hub end port speed is less than 1.2 Mbps;
fragmentation size should be 10 ms, or 80 bytes multiplied by the number of DS0s (For example,
for 4x64k, fragmentation size would be 4x80 = 320 bytes)
•
LLQ on Frame Relay PVC—LLQ is applied under the map class for Frame Relay traffic shaping.
•
cRTP—cRTP is applied under the Frame Relay subinterface; you should use cRTP only if the CPU
utilization is low, and for a small number of calls, depending on platform.
The following configuration example shows how to enable the QoS features described in the previous
section:
Configuration Example 16: QoS for VoIP over Frame Relay WAN Links
Commands
Description
class-map voip
match ip precedence 5
!
Creates the class voip for voice traffic that has been
marked with IP Precedence 5 using one of the available
marking methods.
class-map webtraffic
match ip precedence 3
!
Creates the class webtraffic for web traffic that has been
marked with IP Precedence 3 using one of the available
marking methods.
policy-map llq
class voip
priority 64
class webtraffic
bandwidth 64
class class-default
fair-queue
!
Defines the QoS policy map llq: Class voip traffic gets
priority and is limited to 64 kbps during congestion; class
webtraffic packets are guaranteed 64 kbps. All other
traffic shares the remaining bandwidth.
interface Serial 0/1
no ip address
encapsulation frame-relay
frame-relay traffic shaping
!
Enables Frame Relay traffic shaping. You must enable
Frame Relay traffic shaping to handle speed mismatches
and oversubscription. (LLQ per Frame Relay PVC also
requires Frame Relay traffic shaping.)
interface Serial 0/1.64 point-to-point
ip address 10.14.96.2 255.255.255.252
frame-relay interface-dlci 128
class voice
Attaches traffic shaping class voice to this Frame Relay
PVC.
frame-relay ip rtp header-compression
!
Configures cRTP to reduce the bandwidth requirements of
each voice call.
map-class frame-relay voice
no frame-relay adaptive-shaping
Disables adaptive shaping. We do not recommend
adaptive shaping for VoIP.
frame-relay cir 256000
Sets the CIR or upper transmit rate at 256 kbps.
frame-relay bc 2560
Sets the committed burst rate to 1/100 of CIR.
Page 39
Quality of Service for Voice over IP
VoIP QoS over ATM
39
QoSVoIP.mif
VoIP QoS over ATM
This section describes how to configure VoIP QoS over ATM and includes the following subsections:
•
VoIP QoS over ATM Scenario
•
VoIP QoS over ATM Solution Using Separate Data and Voice ATM PVCs
•
VoIP QoS over ATM Solution Using Shared Data and Voice ATM PVCs
VoIP QoS over ATM Scenario
ATM technology has inherent advantages in handling VoIP traffic because of its small, fixed-size cells
and class of service (CoS) mechanisms. These advantages do not ensure, however, that VoIP traffic will
automatically obtain the QoS it needs from the ATM network carrying it. VoIP traffic will not
automatically obtain the QoS it needs because QoS definitions at the IP layer, such as the IP Precedence
settings in the packet header, do not automatically match ATM CoS settings, namely traffic class
(Constant Bit Rate (CBR), Variable Bit Rate (VBR), Available Bit Rate (ABR), Undefined Bit Rate
(UBR)) and traffic parameters such as Sustainable Cell Rate (SCR), Peak Cell Rate (PCR), and burst
size. Consequently, after data and voice packets are identified and sorted at the IP layer, the network
operator must manually configure the ATM virtual circuits (VCs) to ensure QoS for voice packets
across an ATM network. This manual provisioning is time-consuming, labor-intensive, error-prone,
and, above all, does not scale as more and more voice traffic is introduced into the network.
Figure 11 shows an example of VoIP QoS configured to support ATM.
frame-relay mincir 256000
Sets the minimum acceptable CIR rate. The mincir value
needs to be greater than total priority and bandwidth
allocated.
frame-relay fragment 320
Enables FRF.12 fragmentation with a fragment size of
320 bytes.
service-policy output llq!
Attaches the llq QoS policy to the defined map class.
In this example, Frame Relay traffic shaping handles speed mismatches, FRF.12 fragmentation prevents VoIP
packets from getting delayed behind large data packets, cRTP reduces VoIP bandwidth requirements, and LLQ
provides priority to VoIP traffic and guarantees bandwidth to another class. You need to configure these features on
both ends of the Frame Relay link. FRF.12 is needed only for links less than 1.2 Mbps, and cRTP is recommended
only on links with a low number of VoIP calls and if the CPU is not running too high.
Configuration Example 16: QoS for VoIP over Frame Relay WAN Links (continued)
Page 40
Quality of Service for Voice over IP
VoIP QoS over ATM
40
QoSVoIP.mif
Figure 11
VoIP QoS over ATM Links
Two solutions are available for providing QoS to VoIP over an ATM network: one using separate data
and voice VCs and one using shared data and voice VCs.
VoIP QoS over ATM Solution Using Separate Data and Voice ATM PVCs
For data and voice traffic sharing the same destination but requiring different QoS, you need to define
groups of ATM VCs to form PVC bundles. In a PVC bundle, all the PVCs share the same source and
destination, and each bundle is assigned to carry IP traffic with a specific IP Precedence level or range
of levels. After you configure PVC bundles, you then configure each PVC with its specific ATM QoS
parameters. As voice and data traffic with different IP Precedence levels arrives at the ATM interface
of the router, Cisco IOS software dynamically sends it out on the appropriate PVC, effectively mapping
IP QoS classes to ATM CoSs.
The key benefits of implementing VoIP QoS using this method are as follows:
•
Automatic separation of voice and data traffic onto different PVCs.
•
Preservation of the differentiated services of the IP network through the ATM network.
Cisco
7206
Cisco
7206
ATM
switch
ATM
switch
Ethernet
switch
Ethernet
switch
Ethernet
switch
Ethernet
switch
Ethernet
switch
Cisco 3640
VoIP
gatekeeper
Ethernet
switch
Cisco
3500 VoIP
gateway
AS5300
(8)
PRI
PRI
Cisco
7505
Cisco 3640
VoIP
gatekeeper
Ethernet
switch
Cisco
3500 VoIP
gateway
AS5300
(8)
PRI
PRI
54743
Page 41
Quality of Service for Voice over IP
VoIP QoS over ATM
41
QoSVoIP.mif
The following configuration example shows how to configure VoIP over ATM using PVC bundles to
separate voice and data PVCs:
VoIP QoS over ATM Solution Using Shared Data and Voice ATM PVCs
If you decide to use separate PVCs for voice and data, you must adjust the bandwidth allocation
accordingly as voice traffic grows beyond the bandwidth configured on the voice PVC. This manual
reprovisioning is not necessary when voice and data share the same PVC, provided that voice always
gets the priority it needs. You can configure VoIP traffic to have absolute priority over data traffic by
configuring LLQ on the ATM PVC.
Configuration Example 17: QoS for VoIP over ATM with Separate Voice and Data PVCs
Commands
Description
ip cef
!
Enables IP Cisco Express Forwarding (CEF)
switching. You must enable IP CEF switching for this
solution to work.
interface ATM 2/0/0
no ip address
!
interface ATM 2/0/0.1 point-to-point
ip address 10.1.1.2 255.255.255.252
bundle qosmap
Creates a PVC bundle group called qosmap.
protocol ip 10.1.1.1 broadcast
pvc-bundle control 1/100
precedence 6-7
Maps IP Precedence 6 and 7 traffic to a virtual path
identifier (VPI) or virtual channel identifier (VCI) of
1/100.
pvc-bundle voice 1/101
vbr-rt 6000 5000 1000
precedence 5
Maps IP Precedence 5 traffic (VoIP) to a VPI or VCI
of 1/101 with an SCR of 5 Mbps and some bursting
capabilities.
pvc-bundle web 1/102
cbr 5000
precedence 4
Maps IP Precedence 4 traffic to 1/102 with an SCR of
5 Mbps.
pvc-bundle data 1/103
precedence 0-3
Maps other precedence traffic to a PVC with a VPI or
VCI of 1/103.
In this example, four traffic classes based on IP Precedence are mapped to four separate ATM PVCs
in a bundle. The voice PVC has a guaranteed bandwidth of 5 Mbps with some bursting capabilities,
and the web traffic PVC is also guaranteed 5 Mbps but with no bursting (CBR). Control traffic and
all other traffic flows are not given any ATM rate guarantees.
Page 42
Quality of Service for Voice over IP
Related Documents
42
QoSVoIP.mif
The following configuration example shows how to configure VoIP over ATM using the same PVC for
data and voice traffic:
Related Documents
•
Cisco IOS Quality of Service Solutions Configuration Guide, Release 12.1
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121cgcr/qos_c/index.htm
•
Cisco IOS Quality of Service Solutions Command Reference, Release 12.1
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121cgcr/qos_r/index.htm
•
Cisco IOS Multiservice Applications Configuration Guide, Release 12.1
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121cgcr/multi_c/index.htm
•
Cisco IOS Multiservice Applications Command Reference, Release 12.1
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121cgcr/multi_r/index.htm
Configuration Example 18: QoS for VoIP over ATM using a Shared Voice and Data PVC
Commands
Description
ip cef
!
Enables IP CEF switching. You must enable IP CEF
switching for this solution to work.
class-map voip
match ip precedence 5
!
Creates class voip for voice traffic that has been marked
with IP Precedence 5 using one of the available marking
methods.
class-map webtraffic
match ip precedence 3
!
Creates class webtraffic for web traffic that has been
marked with IP Precedence 3 using one of the available
marking methods.
policy-map llq
class voip
priority 1000
class webtraffic
bandwidth 1000
class class-default
fair-queue
!
Defines policy map llq, which defines the QoS policy:
Class voip traffic gets priority and is limited to 1 Mbps
during congestion; class webtraffic packets are
guaranteed 1 Mbps. All other traffic shares the remaining
bandwidth.
interface ATM2/0/0
no ip address
!
interface ATM2/0/0.1 point-to-point
ip address 10.1.1.2 255.255.255.252
pvc data+voice 1/101
vbr-rt 6000 5000 1000
encapsulation aal5snap!
Configures ATM shaping parameters.
service-policy output llq
!
Attaches the llq QoS policy map to the ATM PVC.
In this example, LLQ is used on a single ATM PVC carrying both VoIP and data. The LLQ policy is applied to an
ATM subinterface for one PVC. Class voip traffic gets priority up to 1 Mbps, and class webtraffic is guaranteed
1 Mbps but does not get priority treatment. ATM shaping also guarantees that the PVC gets a sustained rate of
5 Mbps.
Page 43
Quality of Service for Voice over IP
Related Documents
43
QoSVoIP.mif
•
Cisco IOS Release 12.1(1)T COPS for RSVP feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t1/
copsrsvp.htm
•
Cisco IOS Release 12.1(2)T Class-Based Packet Marking feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t2/cbpmark.
htm
•
Cisco IOS Release 12.1(2)T Class-Based Shaping feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t2/
clsbsshp.htm
•
Cisco IOS Release 12.1(2)T Frame Relay Header Compression Compatibility Enhancements
feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t2/
dtfrhccc.htm
•
Cisco IOS Release 12.1(2)T Low Latency Queueing for Frame Relay feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t2/
dtfrpqfq.htm
•
Cisco IOS Release 12.1(3)T Configuring Burst Size in Low Latency Queueing feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t3/
dtcfgbst.htm
•
Cisco IOS Release 12.1(3)T RSVP Support for Low Latency Queueing feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t3/
rsvp_llq.htm
•
Cisco IOS Release 12.1(5)T Class-Based Marking feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
cbpmark2.htm
•
Cisco IOS Release 12.1(5)T Distributed Class-Based Weighted Fair Queueing and Distributed
Weighted Random Early Detection feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dtcbwred.htm
•
Cisco IOS Release 12.1(5)T Distributed Compressed Real-Time Protocol feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dtdcrtp.htm
•
Cisco IOS Release 12.1(5)T Distributed Low Latency Queueing feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dtllqvip.htm
•
Cisco IOS Release 12.1(5)T Distributed Traffic Shaping feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dtdts.htm
•
Cisco IOS Release 12.1(5)T Implementing DiffServ for End-to-End Quality of Service feature
module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dtdfsv.htm
•
Cisco IOS Release 12.1 (5)T Link Fragmentation and Interleaving for Frame Relay and ATM
Virtual Circuits feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dtlfifra.htm
Page 44
Quality of Service for Voice over IP
Related Documents
44
QoSVoIP.mif
•
Cisco IOS Release 12.1(5)T Traffic Policing feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dtpoli.htm
•
Cisco IOS Release 12.1(5)T VoIP Call Admission Control Using RSVP feature module
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t5/
dt4trsvp.htm
