Type: long Default Value: 0 2.3.258.11 pkid (FI-2938) Type: guid (Unique, Indexed, Not Modifiable) Default Value: newid() Remarks: Unique ID to identify a record. 2.3.258.12 tklicensefeature (FI-2940) Type: enum (Not Modifiable) 2.3.258.13 upgradefromwindows (FI-5079) Type: bool (Not Modifiable) Default Value: FALSE Remarks: The default for UpgradeFromWindows is false 2.3.258.14 version (FI-2944) Type: string [50] (Not Modifiable) Default Value: EMPTY Uniqueness: No multicolumn uniqueness constraints 2.3.259 licenseserver (TI-359) Description: The prioritized list of license servers is specified in this table Records may be modified only by installation and/or DB triggers. Fields: 2.3.259.1 description (FI-2983) Type: string [128] Default Value: EMPTY Validation: ^[]a-zA-Z0-9 !#$'()*+,./:;=?@[^_`{|}~-]{0,128}$ 2.3.259.2 elmlastcontactts (FI-10057) Type: long (Not Modifiable) Default Value: 0 Remarks: This is the time of last contact of the product with the ELM th 2.3.259.3 elmname (FI-25586) Type: string [255] (Unique, Indexed, Null OK) Remarks: Could be hostname or ip address 2.3.259.4 fkprocessnode (FI-2982) Type: guid (Indexed, Cascade Delete) Remarks: associated processnode to license server 2.3.259.5 graceleftdays (FI-5453) Type: long (Not Modifiable)
