cucm/v15/data-dictionary/data-dictionary.md
chunk_id
cucm::v15::data-dictionary::data-dictionary::653

Default Value: 0 2.3.259.6 gracestarttime (FI-5452) Type: long (Not Modifiable) Default Value: 0 2.3.259.7 lastresourceusagecalculationts (FI-10277) Type: string [50] (Not Modifiable) Default Value: 0 Remarks: This is the time stamp for the latest calculation of Licensed R 2.3.259.8 name (FI-2669) Type: string [255] (Unique, Indexed) Remarks: Could be hostname or ip address 2.3.259.9 pkid (FI-2668) Type: guid (Unique, Indexed, Not Modifiable) Default Value: newid() Remarks: Unique ID to identify a record. Rule (RI-259): Type: Active (Insert) Rule Name: Insert of LicenseServer inserts default 0 reco Description: Active rule to ensure that admin stored proce LicenseDistributionUsed table Test Condition: If cannot insert into LicenseDistributionUsed Error Message: Could not insert into LicenseDistributionUsed 2.3.259.10 priority (FI-2670) Type: long (Unique) Default Value: 0 Remarks: Specifies which license server has greater priority for the clu 2.3.259.11 tklicensingmode (FI-10060) Type: enum (Not Modifiable, Null OK) Remarks: This is the Licensing Mode on the product. 2.3.259.12 tklicensingstate (FI-10059) Type: enum (Not Modifiable) Default Value: 1 Remarks: This is the State on the product with reference to Licensing. Uniqueness: No multicolumn uniqueness constraints 2.3.260 licensingresourceusage (TI-1074)

Image 1 from page 451

Image 2 from page 451

Image 3 from page 451

Image 4 from page 451

Image 5 from page 451

Image 6 from page 451

Image 7 from page 451

Image 8 from page 451

Image 9 from page 451
