Description: Contains the resource device tier usage count per user Is not replicated. Records may be modified only by installation and/or DB trigge Fields: 2.3.260.1 adjunct (FI-27573) Type: long Check Constraint: adjunct>= 0 2.3.260.2 bronze (FI-10092) Type: long Check Constraint: bronze>= 0 2.3.260.3 copper (FI-10091) Type: long Check Constraint: copper>= 0 2.3.260.4 em (FI-10087) Type: bool Default Value: FALSE Remarks: True if EM is configured for user. 2.3.260.5 fkenduser (FI-10086) Type: guid (Unique, Indexed, Cascade Delete, Not Modifiable, Null O Remarks: Unique ID of enduser whose device usage is counted, null for 2.3.260.6 gold (FI-10094) Type: long Check Constraint: gold>= 0 2.3.260.7 pkid (FI-10085) Type: guid (Unique, Indexed, Not Modifiable) Default Value: newid() Remarks: Unique identifier for the record 2.3.260.8 presence (FI-10096) Type: bool Default Value: FALSE Remarks: TRUE if user has IM And Presence. 2.3.260.9 silver (FI-10093) Type: long Check Constraint: silver>= 0 2.3.260.10 snr (FI-10088) Type: bool Default Value: FALSE Remarks: True if SNR is configured for user. 2.3.260.11 telepresence (FI-10095)
